Jumper position see figure WINDOW TRANSMITTERS,
point 12.
BRIEF INSTRUCTIONS
Factory settings
Press and hold the reset button
(see fig. CENTRAL UNIT, point 7)
The unit will beep once after approx. 1 second and
4 green LEDs will flash.
There will be 3 beeps after another 7 seconds
followed by a pause and 3 more beeps. The
power LED will light constantly
Release the reset/learn button; the device is now
set to default
Teaching the sensors:
(All the sensors to be taught are ready for operation)
1. Make sure that the jumper for AND/OR connection is set
correctly for each transmitter.
2. Briefly press the reset button on the central unit
(fig. CENTRAL UNIT, point 7).
3. Briefly press the learn button on the first sensor.
4. After approx. 10 seconds, the corresponding LED lights
up constantly depending on the sensor and the central
unit emits a beep.
5. Briefly press the learn button on the next sensor (e.g. if
this is a second window contact, the central unit emits
two beeps, with the third window contact 3 beeps, etc.).
6. Wait approx. 50 seconds after the last sensor, the
central unit then ends the learning process and displays
the status of the sensors via the LEDs.
The central unit and the transmitters are now ready
for operation.
LED indications:
Window closed
Window LED red
Window open
Window LED green
Stove on
Stove LED red
Stove off
Stove LED green
Roller shutter closed
Roller shutter LED red
Roller shutter open
Roller shutter LED green
The relay will only switch if:
With window contact only:
Window open
With window and stove contact:
Stove off
Stove on and window open
With window and roller shutter and stove contact:
Stove off
Stove on, window and roller shutter open
EN
37
