3. Insert the thermal sensor as far as possible into the hole
that you have drilled for it.
4. Move the mounting bracket on the thermal sensor
until it is lying on the exhaust pipe and then mark the
two attachment holes on the mounting bracket with a
suitable pen. Then remove the thermal sensor and the
mounting bracket from the exhaust pipe again.
5. Drill 2 mm holes at the two positions you have marked
for mounting on the exhaust pipe.
NOTE
If you have a double-walled exhaust pipe then take
care to drill the mounting holes only through the
outer pipe.
6. Fix the mounting bracket to the exhaust pipe by
screwing it with the two included tapping screws and
the two drilled holes as described above.
7. Now feed the thermal sensor through the mounting
bracket as far as possible and fix it to the mounting
bracket using the side screw. Do not tighten the screw
too far to avoid damage to the thermal sensor.
8. Lay the wire to the stove transmitter.
9. Connect the wire on the thermal sensor to the stove
transmitter and the wire marked in red to the screw
ROT / RED and the wire marked in black to the screw
SCHWARZ / BLACK.
10. There is a wall mount on the back of the stove
transmitter. This can be pushed down and removed
from the stove transmitter.
11. Remove the cover from the stove transmitter and insert
the 2 x AA batteries with the correct polarity as marked.
Then you can slide the cover back on.
12. Look for a suitable location to attach the stove
transmitter and screw the wall bracket for the
transmitter into place. The stove transmitter should be
at least 50 cm away from the exhaust pipe so that the
transmitter cannot be destroyed by heat. Also the stove
transmitter should not be attached behind cladding as
this limit its range.
INITIAL OPERATION
Before you start encoding, the jumpers of the window
transmitter must be set correctly. If only one window
transmitter is used, the jumper must be set in position
“OR”. If several window transmitters are to be used, they
can be either AND-linked (each window must be open) or
OR-linked (one of the windows must be open).
In case of AND connection, the jumper of the first
window transmitter must be set in position “AND”, the
last in position “OR”.
With an “OR” link, the jumper must be in the “OR”
position for all window transmitters.
EN
36
