10. Close the casing on the transmitter, the magnet and the
sensor with the correct cover.
Attachment points:
• It must be ensured that the gap between the magnet
and the sensor is less than 6 mm when the roller
shutter is open.
• The contact must be attached to the top or side window
frame and casement in such a way that the distance
between the two casing sections is less than 6 mm
when the window is closed! Use the included packing
(U) to make these adjustments.
• We recommend attaching the contact and the magnet
with the double-sided sticky tape before the final
attachment and only to screw them in place at the end.
Testing the function of the roller
shutter sensor
• Slowly move the roller shutter to the open position,
then the green LED on the roller shutter sensor (OPEN)
will flash briefly before the open position.
• Close the roller shutter, then the red LED (CLOSED)
will flash briefly.
Instructions for attaching the
stove transmitter
AS-T30 (15 and T)
NOTE
The stove should be switched off and cool in order to
avoid burns to your skin.
The distance between the installation point of the
temperature measuring device and the exhaust stack of
the room air-dependent fireplace in the connecting piece
must not exceed a maximum of 1.5 m. The temperature
sensor must extend into the exhaust gas stream by at
least 30 mm and a maximum of 100 mm, whereby
a homogeneous flow around the temperature sensor
by the core flow of the exhaust gas must be ensured.
Regular inspection and, if necessary, cleaning must be
carried out.
The thermal sensor (figure 3) is fed into the exhaust
pipe through a hole and screwed to the stove pipe using
the included mounting bracket. The stove transmitter
should not be covered by cladding as this impedes the
radio signal and reduces the range.
1. Drill a 4 mm hole in a suitable position in the exhaust
pipe for the thermal sensor. If possible ensure that the
hole is positioned in such a way that the thermal sensor
cannot be seen after attachment.
2. Slide the mounting bracket over the thermal sensor
but do not tighten the screw to attach the thermal
sensor yet.
EN
35
