5. Once all the functions have been tested successfully
the transmitter and the receiver must be screwed to the
window/window frame. There is a prepared hole for
this purpose on the lower casing section of the window
transmitter and in the lower magnet casing section.
These can be used to screw the window transmitter
and the magnet to the window/window frame. This
prevents the window transmitter and the magnet from
falling down unintentionally.
6. Replace the magnet and close the magnet casing with
the cover.
Attachment points:
• It must be ensured that the gap between the magnet
and the contact is less than 6 mm when the window
is closed.
• The contact must be attached to the upper or side
window frame and casement in such a way that the
distance between the two sections of the casing is
less than 6 mm when the window is closed. Use
the included packing (U) to adjust the parts for
this purpose.
• We recommend attaching the contact and the magnet
with the double-sided sticky tape before the final
mounting and to only screw the elements in place at
the end.
Testing the function of the window tilt
and swivel position
• Slowly move the window to the tilt or swivel position,
then the green LED on the window transmitter (OPEN)
will flash briefly before the maximum tilt or
swivel position.
• Close the window, then the red LED (CLOSED) will
flash briefly.
• Finally check the opening gaps again using the
minimum value determined in accordance with Table 1.
Attaching the roller shutter transmitter
AS-R40 (20 and 25)
NOTE
Attach the roller shutter transmitter and the
magnet to the window and the frame for the initial
operation using double-sided sticky tape. Once the
function test has been completed then the roller
shutter transmitter and the magnet can be
screwed in place
Attaching the roller shutter transmitter
The roller shutter transmitter and the magnet must
be attached as shown in figure 4. The roller shutter
transmitter must be attached to the inside of the
window in the vicinity of the opened roller shutter.
Alternatively the transmitter may also be attached
between the window and the roller shutter but this
will weaken the radio signal. The attachment point
must be selected in such a way that a ‘roller shutter
EN
33
