This section describes attachment of the window
transmitter for a tip and swivel window.
a) Attachment for the tilt position
The window transmitter and the magnet must be
attached as shown in figure 2 TILT POSITION. The
window transmitter must be attached near the hinge
for the tilt position. The attachment point must be
selected in such a way that a ‘window open’ signal is
only produced once the necessary opening is achieved
in accordance with the table.
b) Attachment for swivel position
The window transmitter and the magnet must be
attached as shown in figure 2 SWIVEL POSITION. The
window transmitter must be attached near the hinge
for the swivel position. The attachment point must be
selected in such a way that a ‘window open’ signal is
only produced once the necessary opening is achieved
in accordance with the table.
Proceed as follows to attach the window transmitter:
1. Attach the lower casing section of the window
transmitter at the correct position using the included
double-sided sticky pad.
Alternatively there is a prepared hole in the lower
casing section to screw the window transmitter onto
the window frame. To use this carefully remove the
printed circuit board from the lower casing section and
screw the casing in place using the included screw.
Then carefully replace the printed circuit board.
2. Insert the battery (1x size CR2477) into the
transmitter with the correct polarity and fix it in place.
NOTE
Please ensure that you lay the battery in the
window transmitter on top of the metal tab and
not below it.
3. Press the upper casing section onto the lower
casing section.
Attaching the magnet
Fix the magnet in place in accordance with figure 1.
Open and close the window once after attachment. The
transmitter should flash at least once for each
activation. Proceed as follows to attach the magnet:
1. Fix the lower magnet casing section at the correct
position using the included double-sided sticky pad.
2. Insert the magnet and check the function of the
window transmitter.
CAUTION!
The distance between the window transmitter and
the magnet may not be more than 6 mm
3. Open the window again. The green LED (OPEN) should
flash briefly if the transmitter is installed correctly.
4. Now close the window. The red LED (CLOSED) should
flash briefly.
EN
32
