6
6. Pressure regulator
7. Air filter (dehydrator)
8. Compressor
The maximum supply pressure during the
tool operation with the trigger fully pressed and full pressure
controller opening should not exceed 0.63 MPa /
6.3 bar / 91.3 psi. Too low pressure reduces the device power and rpm, while
too high may damage certain components permanently.
Before you start the tool for the first time, use the oilcan (4) to insert 3-5
drops of oil with SAE 10 viscosity directly to the air inlet (1) (see Fig. A2)
Use only the oil designed for pneumatic devices. Do not use the oil with
detergents or other additives as this could lead to sooner wear of the
sealing components in the device.
(see Fig. A3).
(see Fig. A4).
STORAGE:
O
10 C.
n
TRANSPORT:
n
ENVIRONMENTAL PROTECTION:
2. Set the appropriate tool rotation direction and the torque in case of
tightening.
3. Install the appropriate socket on the tool drive.
4. Connect the impact wrench to the pneumatic system.
It is strictly recommended to install the air filter, pressure controller and
5. Insert the wrench with the socket installed on the item to be screwed
lubricator as presented in the drawing. This will ensure clean air flow with
out or in.
the appropriate pressure and oil mist to the tool and the most effective
6. Press the tool switch gradually (9).
use of the tool for a longer time.
7. After you have finished working, disassemble the pneumatic system
PLEASE NOTE!
and carry out the tool maintenance.
PLEASE NOTE! When you open the quick-release coupling,
hold the pressure hose to protect against being hit by it
("pulsating hose" effect). Injury hazard!
Instructions:
If you are unable to detach the connection within 5 seconds, stop the work
with your tool. In such circumstances, you should use penetrating corrosion
removers or freezing agents and try to dismount again.
When connecting the threaded connections, including but not limited to
Screw the air inlet connector (3), enabling to connect the air supply hose,
tightening the bolts holding the passenger vehicle wheels, always follow
strongly and securely onto the air inlet thread The connector
the maximum forces specified by the manufacturer. The impact wrench is
designed solely for light screwing in (not heavy tightening) of bolts and
thread should be sealed with Teflon.
nuts. The bolts and nuts should be tightened with a torque wrench in line
Install the appropriate impact socket (7) on the tool drive (6)
with the appropriate requirements.
PLEASE NOTE! Use only accessories designed for impact
tools for such tools.
MAINTENANCE AND
Do not install the socket on the wrench drive without the
Clean the tool thoroughly after you have completed the task.
safety ring. Whenever possible, use the sockets with the lowest wear as the
Do not use petrol, solvent or any other flammable liquid to clean
worn socket attachment may damage the drive.
the tool. The vapours may ignite, causing the tool explosion and
Using the controller (5), set the appropriate rotation direction (see Fig.
serious injuries.
A.5) and adjust the pressure (the torque applied to the nut or bolt).
Always store the impact wrench in dry rooms above
Setting "1" of the controller corresponds to the lowest torque and is
All pneumatic system components must be protected against pollution.
recommended for bolts and nuts with the smallest diameter. Setting "3"
Any pollutants that get inside the pneumatic system may damage the
corresponds to the highest torque generated.
tool and other pneumatic system components.
PLEASE NOTE!Switch the tool off before every change of the
During prolonged storage insert some drops of oil designed for
rotation direction and power. It may be damaged in any
pneumatic tools inside the tool. Connect the tool to the pneumatic
other case.
system and start for a short time to spread the oil on the mating surfaces.
Connect the tool to the pneumatic system, using the hose with the
After you disconnect the tool, remove excess oil which escaped via the
minimum internal diameter of 10 mm and the maximum length of 6 m.
outlet openings. If the oil is left, it may damage the tool seals.
Ensure the hose strength is at least 0.63 MPa.
After 100 hours of the tool operation or 6 months after the operation
Switch the tool on for a couple of minutes and check if it does not
start, it is recommended to have the tool inspected and cleaned by the
generate any strange noise or vibrations.
specialised service technicians. If the tool was used without the
Work with impact sockets
recommended air supply system, increase the frequency of the tool
Before you start screwing the bolt or nut in with the wrench, screw the
inspections.
bolt or nut manually onto the thread (at lease a couple of rotations).
If it is necessary to replace any part, always use the original components.
Ensure you have selected the appropriate socket size for the item screwed
Using other components may reduce the tool efficiency and eliminate
in or out. Inappropriate size selection may damage both the socket and
any claims resulting from the warranty rights.
the nut or bolt.
Screwing out and in
The disassembled device should be transported and stored in the original
PLEASE NOTE! When you screw bolts and nuts out, they are
packaging.
inside the impact socket. You, other people and property
may be injured or damaged by ejected parts.
MANUFACTURER:
Ensure the rotation direction is set correctly before you operate the tool. Do
not start the tool before you place the socket on the threaded connection!
When you operate the impact wrench, the vibrations caused by it may be
transferred to the operator. Always use work gloves when you work.
1. Control the pressure in the pneumatic system to ensure it does not
exceed the maximum value for a given tool.
Worn tools are recyclable and should not be discarded into the household
.
PROFIX Sp. z o.o.,
03-228 Warszawa,
ul. Marywilska 34, POLAND
