21
5. STEREO LEFT TOP OR MONO A+B TOP SPEAKER OUTPUT
In STEREO or DUAL mode this SPEAKON connector sends the amplied TOP LEFT signal to a TOP speaker.
In MONO or DOUBLE modes this SPEAKON connector sends the amplied TOP signal to both TOP A&B speakers when
they are linked in a single column. In these modes use always the supplied 4-wire SPEAKON cable for connecng the
TOPS.
Note: we recommend to not connect any other speaker system to this dedicated power output. Use always a power
cable to connect the TOP speakers.
This connector is wired in this way:
• PIN 1+ connected to POSITIVE output of amplier LEFT channel
• PIN 1- connected to NEGATIVE output of amplier LEFT channel
• PIN 2+ connected to POSITIVE output of amplier RIGHT channel
• PIN 2- connected to NEGATIVE output of amplier RIGHT channel
6. STEREO RIGHT TOP SPEAKER OUTPUT
In STEREO or DUAL modes this SPEAKON connector sends the amplied TOP RIGHT signal to a TOP speaker.
In MONO or DOUBLE modes it is not used.
Note: we recommend to not connect any other speaker system to this dedicated power output. Use always a power
cable to connect the TOP speakers.
This connector is wired in this way:
• PIN 1+ connected to POSITIVE output of amplier LEFT channel
• PIN 1- connected to NEGATIVE output of amplier LEFT channel
• PIN 2+ not connected
• PIN 2- not connected
7. DSP EDIT Encoder / Buon
Push and turn this knob to edit the DSP parameters (see DSP SETTINGS for detailed instrucons). If you press this buon
while switching on the loudspeaker that will force a full RESET of the DSP and it will recall the factory default sengs.
8. LCD DISPLAY
The display shows the current DSP status (current preset, digital signal aenuaon, input level) and it is used to access
the DSP parameters (see DSP SETTINGS for detailed instrucons).
9. POWER switch
Speaker is "ON" when the switch is in the "I" posion.
NOTE: When you shut down your equipment, turn o the speakers rst. When powering up, turn on the speakers last.
10. LINE VOLTAGE selector
This switch sets the AC voltage line of your country (usually it is set by factory and isn't necessary to change it). The
115V seng is for mains line in the range of 105-120V~ and 230V seng is for mains line in the range of 210-240V~.
WARNING: AN INCORRECT SETTING OF AC LINE VOLTAGE COULD DAMAGE SERIOUSLY THE ELECTRONICS!
11. FUSE holder
Here is placed the mains protecon fuse.
WARNING: REPLACE THE PROTECTION FUSE ONLY WITH SAME TYPE AS SHOWN ON THE PRODUCT.
IF, AFTER THE REPLACEMENT, THE FUSE BLOWS AGAIN, DO NOT REPLACE IT AGAIN BUT CONTACT THE NEAREST
PROEL SERVICE CENTER.
12. AC~ socket
Here’s where you plug in your speaker’s mains supply cord. You should always use the mains cord supplied with the
speaker. Be sure your speaker is turned o before you plug the mains supply cord into an electrical outlet.
13. FAN
These are the slots for the air intake of the fan for internal cooling, leave them free from any object.
