The stapler may only be operated with a compressor or a compressed air system under the
following conditions:
• The operating pressure of the compressor or compressed air system must not exceed the
maximum operating pressure for the stapler by more than 10%. Information about the
operating pressure for the stapler can be found in this chapter.
• In the case of compressed air systems with a higher pressure, a pressure control valve
(pressure reducer) with a downstream pressure relief valve must be fitted in the
compressed air line.
• The compressed air must be filtered, dry and oiled with PREBENA special nailer oil.
• A compressed air conditioner must be mounted on the coupling side at the outlets for
the compressed air line to the stapler. This should comprise
- a filter,
- a water separator and
- an oiler.
• If an oiler is not installed, the length of the air line to the stapler must not exceed 10m.
Otherwise, two to five drops of PREBENA special nailer oil need to be poured directly
into the air inlet of the stapler every day before putting it into operation.
• The compressed air system must be capable of maintaining the operating pressure even
with the desired air extraction.
• The inside diameter of the air line must be at least 13 mm.
• The connection for the stapler must be fitted with a quick coupling with NW 10 and an
inside diameter of at least 10 mm.
CAUTION
Operating the stapler with compressed air systems that do not meet the
above requirements may cause damage to it.
Only operate the stapler with suitable compressed air systems.
Only use the stapler if it is in a flawless condition.
Check the condition of the stapler.
Check the compressed air hose connection for foreign bodies and dirt and clean as necessary.
Set the operating pressure at the compressor pressure regulator to 4.5 - 7.5 bar.
WARNING
Unintentionally activating the stapler when connecting it to the
compressed air supply can result in serious or fatal injury.
Do not point the stapler at people or animals.
Empty the magazine before connecting the stapler.
CAUTION
Damaged hose lines can burst, and the escaping compressed air could
cause material damage.
Check the compressed air system and the stapler for material
damage before connecting them.
Only connect the stapler to a functioning compressed air system.
