Assembly Instructions
Assembling the stapler
The assembly procedure can vary on account of the differences in production systems.
CAUTION
When assembling the drive stapler, body parts could get clamped and
crushed between the stapler and the production plant.
Have the installation tool ready at hand (ring/open-ended wrench SW24)
Place the stapler in the designated assembly position and secure it with the fastening nut and
tool.
Tighten the fastening nut to 210 Nm.
The height is adjusted on the plant.
Connecting the stapler to the compressed air supply
Only connect the stapler to the compressed air supply after it has been attached to
the production system as described in the installation instructions.
The stapler can be connected to a compressor or a compressed air system.
