Important
Damaged hose lines can burst, and the escaping compressed air could cause material damage.
Check the compressed air system and the stapler for damage before connecting them.
Only connect the stapler to a functioning compressed air system.
Push the quick-release lock (1) of the compressed air hose onto the connection (2) until it
audibly engages.
Check the operating pressure indicated on the compressor pressure gauge.
Connecting the stapler to the control line
Only connect the stapler to the compressed air supply after it has been attached to the
production system as described in installation instruction 2.
A 6-pin XLR type connector plug must be used. The pin assignment is described in the chapter
"Circuit diagrams".
WARNING
Defective cable connections and exposed contacts can result in personal
injury and material damage.
Check the cable connection for possible damage.
Only attach the stapler to a flawless cable connection.
Push the connecting cable (1) onto the connection socket (2) until it audibly engages.
