• Replace worn or damaged sanding discs and sand-
ing belts immediately.
• Always use the protective cover and the workpiece
support as required for the insert tools.
• Always use the electric tool with insert tools on both
spindles to limit the risk of contact with the rotating
spindle.
5.7 Residual risks
The power tool is state-of-the-art and has been built
according to the recognised technical safety
regulations. However, individual residual risks can
arise during operation.
• Risk of injury for fingers and hands due to the rotat-
ing sanding disc with improper guiding or position-
ing of the tool to be sanded.
• Risk of injury from tools thrown away due to improp-
er holding or guiding.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the "Safety In-
structions" and the "Intended Use" together with the
operating manual as a whole are observed.
WARNING
This power tool generates an electromagnetic field
during operation. This field can impair active or pas-
sive medical implants under certain circumstances. In
order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the power tool.
6 Technical data
AC motor 230-240 V∼/50 Hz
Rated input S1* 370 W
Dimensions L x W x H 480 x 400 x 310 mm
ø disc 150 mm
RPM disc 2980 rpm
Grinding belt size 915 x 100 mm
Grinding belt speed 7.3 m/s
Angle positioning 0° − 90°
Table size 195 x 136 mm
Table angle positioning 0° − 45°
Weight approx. 10 kg
Subject to technical changes!
Operating mode S1 (continuous operation)
The product can be operated continuously with the
specified power.
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined
in accordance with EN 62841-1.
Sound pressure L
pA
79.4 dB
Sound power L
wA
89.9 dB
Uncertainty K
wA
3 dB
The total vibration emission values specified and the
device emissions values specified have been measured
in accordance with a standardised test procedure and
can be used for comparison of one electric tool with an-
other.
The total noise emission values specified and the total
vibration emission values specified can also be used for
an initial estimation of the load.
Note:
• The vibration values and noise emission values can
vary from the specified values during the actual use
of the electric tool, depending on the type and the
manner in which the electric tool is used, and in par-
ticular the type of workpiece being processed.
• It is necessary to define safety measures to protect
the operator which are based on an estimate of vi-
bration exposure during the actual operating condi-
tions (for this, all parts of the operating cycle have
to be considered, e.g. times during which the power
tool is switched off and times during which it is
switched on but runs in no-load mode).
7 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suf-
focating!
• Open the packaging and carefully remove the prod-
uct.
• Remove the packaging material, as well as the
packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the
transport company that delivered the Product. Later
claims will not be recognised.
• If possible, keep the packaging until the expiry of
the warranty period.
• Familiarise yourself with the product by means of
the operating manual before using for the first time.
26 | GB www.practixx.com
