TROUBLE SHOOTING

Problem LCD/LED/Buzzer Explanation / Possible cause What to do

Unit shuts down

automatically during

startup process.

LCD/LEDs and buzzer

will be active for 3

seconds and then

complete off.

The battery voltage is too low

(<1.91V/Cell)

1. Re-charge battery.

2. Replace battery.

No response after

power on.

No indication.

1. The battery voltage is far too low.

(<1.4V/Cell)

2. Battery polarity is connected

reversed.

1. Check if batteries and the

wiring are connected well.

2. Re-charge battery.

3. Replace battery.

Mains exist but the

unit works in battery

mode.

Input voltage is

displayed as 0 on the

LCD and green LED is

flashing.

Input protector is tripped

Check if AC breaker is tripped

and AC wiring is connected well.

Green LED is flashing.

Insufficient quality of AC power.

(Shore or Generator)

1. Check if AC wires are too thin

and/or too long.

2. Check if generator (if applied)

is working well or if input

voltage range setting is correct.

(UPSAppliance)

Green LED is flashing.

Set “Solar First” as the priority of

output source.

Change output source priority to

Utility first.

When the unit is

turned on, internal

relay is switched on

and off repeatedly.

LCD display and LEDs

are flashing

Battery is disconnected.

Check if battery wires are

connected well.

Buzzer beeps

continuously and red

LED is on.

Fault code 07

Overload error. The inverter is

overload 110% and time is up.

Reduce the connected load by

switching off some equipment.

Fault code 05 Output short circuited.

Check if wiring is connected well

and remove abnormal load.

Fault code 02

Internal temperature of inverter

component is over 100°C.

Check whether the air flow of

the unit is blocked or whether

the ambient temperature is too

high.

Fault code 03

Battery is over-charged. Return to repair center.

The battery voltage is too high.

Check if spec and quantity of

batteries are meet requirements.

Fault code 01 Fan fault Replace the fan.

Fault code 06/58

Output abnormal (Inverter voltage

below than 190Vac or is higher than

260Vac)

1. Reduce the connected load.

2. Return to repair center

Fault code 08/09/53/57 Internal components failed. Return to repair center.

Fault code 10 Surge

Restart the unit, if the error

happens again, please return to

repair center.

Fault code 12 DC/DC over current or surge.

Fault code 51 Over current or surge.

Fault code 52 Bus voltage is too low.

Fault code 55 Output voltage is unbalanced.

Fault code 56

Battery is not connected well or fuse

is burnt.

If the battery is connected well,

please return to repair center.

Fault code 11 Solar input voltage is more than 450V.

Solar input voltage is more than

450V.
