SPECIFICATIONS

MODEL

3.6KW

RATED OUPUT POWER

3600W

PV INPUT (DC)

Max. PV Power

5000W

6000W

Max. PV Array Open Circuit Voltage

500 VDC

PV Input Voltage Range

120 VDC~500 VDC

MPPT Range @ Operating Voltage

120 VDC~430 VDC

Max. PV Array Short Circuit Current

18A

27A

Number of MPP Tracker

1

GRID-TIE OPERATION

GRID OUTPUT (AC)

Nominal Output Voltage

220/230/240 VAC

Feed-in Grid Voltage Range

195.5~253 VAC @India regulation

184 ~ 264.5 VAC @Germany regulation

184 ~ 264.5 VAC @South America regulation

Feed-in Grid Frequency Range

49~51Hz @India regulation

47.5~51.5Hz @Germany regulation

57~62Hz @South America

Nominal Output Current

15.6A

24.3A

Power Factor Range

>0.99

Maximum Conversion Efficiency (DC/AC)

96%

OFF-GRID, HYBRID OPERATION

GRID INPUT

Acceptable Input Voltage Range

90 - 280 VAC or 170 - 280 VAC

Frequency Range

50 Hz/60 Hz (Auto sensing)

Transfer Time

< 10ms (For UPS)

< 20ms (For Home Appliances)

< 50ms (For parallel operation)

Rating of AC Transfer Relay

40A

BATTERY MODE OUTPUT (AC)

Nominal Output Voltage

220/230/240 VAC

Output Waveform

Pure Sine Wave

Efficiency (DC to AC)

93%

BATTERY & CHARGER

Nominal DC Voltage

48 VDC

Maximum Charging Current (from Grid)

100A

120A

Maximum Charging Current (from PV)

100A

120A

Maximum Charging Current

100A

120A

GENERAL

Dimension, D X W X H (mm)

140 x 295 x 468

Net Weight (kgs)

11

12

INTERFACE

Parallel-able

Yes

External Safety Box (Optional)

Yes

Communication

RS232/Dry-Contact/WiFi

ENVIRONMENT

Humidity

0 ~ 90% RH (No condensing)

Operating Temperature

-10°C to 50°C

5.6KW

5600W

450 VDC

120 VDC~450 VDC
