3 OM-POWER PREP ADVANCED
IMPORTANT
: DO NOT BEND THE EDGE OF THE BACKSPLASH WHEN LAYING THE SINK ON
ITS BACK.
COMPONENT INSTALLATION
Lay the sink on its back to allow access to the bottom of the sink. Be careful to not
let the sink assembly drop to the oor with an impact that would damage the sink
assembly or the oor. It may be necessary to place some cardboard or a tarp on the
oor to protect the nish.
DRAIN WITH BUILT-IN VALVE IS INSTALLED IN THE BOTTOM OF THE TANK
The sink must be accessible from its top side and its bottom side in order to install
the accessories. Be aware that the backsplash is unsupported at this time and can
be bent out of shape by trying to support the entire weight of the sink on the edge of
the backsplash.
IMPORTANT
: THE RIM OF THE DRAIN MUST SEAT IN THE RECESS OF THE SINK OR IT
WILL WORK LOOSE OVER TIME AND ALLOW WATER TO LEAK AROUND THE
DRAIN.
Install Sink Drains
There is one sink drain for every sink in the Power Prep Advanced that must be
installed. The drains with valves built into their bodies are installed in the bottoms
of the sinks and oriented with the drain valve handle toward the front of the sink.
Each drain ange must be sealed to its mating surface in the sink using a sealant or
plumbers putty. The rubber ring provided with the drain is not a gasket; it is a vibration
dampener used between the nut and the bottom surface of the sink. It will not create
a water tight seal. The thin Teon ring is provided to reduce friction during tightening
of the drain nut; it is installed between the nut and the rubber ring. See the illustration
at below.
The drains with built-in valves will be oriented with the handle connection toward the
front of the sink. From inside the sink, insert the drain through the drain hole and seat
the ange against the sheet metal surface of the tank. Be sure that the sealant (or
putty) compresses so the rim of the drain actually touches the sheet metal surface of
the sink. If the drain does not touch the sink it will work loose and leak as the sealant
compresses over time.
From the outside of the sink, place the rubber vibration ring over the threaded body
of the drain followed by the Teon ring and then the drain nut. Tighten the nut “hand
tight” until it is time to install the handle.
Using two nuts, attach the drain handle bracket to the studs on the bottom of the
tank. Insert the drain valve handle through the bracket and into the drain body. It
may be necessary to rotate the handle a partial turn to align the ats on the end of
the handle shaft with the ats on the valve so that the handle will fully insert into the
valve. Secure the handle to the valve body by screwing the handle nut onto the valve
body connection.
While holding the drain body to prevent it from rotating, tighten the ange nut with a
wrench to rmly seat the nut against the rubber vibration ring and the vibration ring
against the surface of the sink (approximately ¼ turn past “hand tight”). Wipe or trim
the excess sealant from around the drain ange inside the sink. Allow the sealant to
dry before lling the sink with water. See the instructions on the side of the sealant
container for drying time.
