User’s Manual of IGS-5225 series
263
4.3.12.1 MVR Configuration
. This page provides MVR related configuration. The MVR screen in Figure 4-3-12-1 appears
Figure 4-3-12-1: MVR Configuration Page Screenshot
The page includes the following fields:
Object
Description
MVR Mode
Enable/Disable the Global MVR.
The Unregistered Flooding control depends on the current configuration in IGMP/MLD
Snooping.
It is suggested to enable Unregistered Flooding control when the MVR group table is full.
Delete
Check to delete the entry. The designated entry will be deleted during the next save.
MVR VID
Specify the Multicast VLAN ID.
Be Caution: MVR source ports are not recommended to be overlapped with
management VLAN ports.
MVR Name
MVR Name is an optional attribute to indicate the name of the specific MVR VLAN.
Maximum length of the MVR VLAN Name string is 16. MVR VLAN Name can only
contain alphabets or numbers. When the optional MVR VLAN name is given, it should
contain at least one alphabet. MVR VLAN name can be edited for the existing MVR
VLAN entries or it can be added to the new entries.
