User’s Manual of IGS-5225 series
264
IGMP Address
Define the IPv4 address as source address used in IP header for IGMP control frames.
The default IGMP address is not set (0.0.0.0).
When the IGMP address is not set, system uses IPv4 management address of the IP
interface associated with this VLAN.
When the IPv4 management address is not set, system uses the first available IPv4
management address. Otherwise, system uses a pre-defined value. By default, this value
will be 192.0.2.1.
Mode
Specify the MVR mode of operation. In Dynamic mode, MVR allows dynamic MVR
membership reports on source ports. In Compatible mode, MVR membership reports are
forbidden on source ports. The default is Dynamic mode.
Tagging
Specify whether the traversed IGMP/MLD control frames will be sent as Untagged or
Ta gged with MVR VID. The default is Tagged.
Priority
Specify how the traversed IGMP/MLD control frames will be sent in prioritized manner.
The default Priority is 0.
LLQI
Define the maximum time to wait for IGMP/MLD report memberships on a receiver port
before removing the port from multicast group membership. The value is in units of tenths
of a seconds. The range is from 0 to 31744. The default LLQI is 5 tenths or one-half
second.
Interface
Channel
Setting
When the MVR VLAN is created, select the IPMC Profile as the channel filtering condition
for the specific MVR VLAN. Summary about the Interface Channel Profiling (of the MVR
VLAN) will be shown by clicking the view button. Profile selected for designated interface
channel is not allowed to have overlapped permit group address.
Port
The logical port for the settings.
Port Role
Configure an MVR port of the designated MVR VLAN as one of the following roles.
Inactive: The designated port does not participate MVR operations.
Source: Configure uplink ports that receive and send multicast data as source ports.
Subscribers cannot be directly connected to source ports.
Receiver: Configure a port as a receiver port if it is a subscriber port and should only
receive multicast data. It does not receive data unless it becomes a member of the
multicast group by issuing IGMP/MLD messages.
Be Caution: MVR source ports are not recommended to be overlapped with
management VLAN ports.
Select the port role by clicking the Role symbol to switch the setting.
I indicates Inactive; S indicates Source; R indicates Receiver
The default Role is Inactive.
Immediate
Leave
Enable the fast leave on the port.
Buttons
: Click to add new MVR VLAN. Specify the VID and configure the new entry. Click "Save"
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
