User’s Manual of ICA-x80 series
57
Step 3: Select the area to set the motion detection sensitivity, click "Apply".
【Select All】Motion detection range is to monitor all of the areas, which consist of 396 (22 x 18)
small squares.
【Manually draw the alarm area】Move the mouse to the preview screen and click the left mouse
button to select the range of motion detection. Release the left mouse button to complete the alarm
area selection. A camera can select multiple motion detection zones at the same time.
【Clear All】Clearing all the motion detection areas that were selected.
【Sensitivity】The default is 5. The range is from 0 to 10. The larger the value, the easier for the
device to trigger an alarm.
Step 4: Set the arming schedule.
As shown in Figure 8-21 below, you can view, edit, and delete the arming time of motion detection.
The default is to arm the alarm 24 hours a day. You can adjust the arming time as follows:
- Method 1: Click the arming time period, manually fill in the start time and end time, set up and
click "Apply". If you need to delete the time period, click the "Delete" button and then reset the
time period.
- Method 2: Click the arming time period, two arrows will be displayed at both ends of the time
period. Move the adjustment arrow left or right to adjust the arming time.
- You can set up more than one time period for up to 8 time periods.
- After the day of deployment time is set, if the other time also needs to be set at the same
arming time, click the right side of the timeline " " copy button; in the "copy to" interface,
check the "Select All" or a day, and then Click "OK".
- After setting, click "Apply" to complete the setting of the arming time.
Figure 8-21
