~ 52 ~
➢ When an exhaust duct is used, the ending of the exhaust hose must be adjusted
into the direction of flow.
➢ If the exhaust duct passes through cool areas (e.g., an attic), a temperature
gradient may occur in the different parts of the exhaust duct so condensate will
be generated. Proper insulation of the corresponding parts of the exhaust duct
will then be needed. Equip such an exhaust duct with a condensate trap if need
be.
➢ Depending on the appliance model the hood is equipped with one (top) or
two (top, back) outlets. The idle outlet is covered by a plastic cap. You can remove
this cap by turning it anticlockwise. Use the cap to cover the idle outlet.
2.3 Minimum distances
❖ The minimum distance between the extractor hood and a hob must be at least
65.00 cm.
❖ The maximum distance between the extractor hood and a hob must not exceed
80.00 cm.
Strictly observe the minimum distance between the extractor hood and the
hob.
It is also absolutely necessary to observe the individual minimum
distances between hobs and extractor hoods; these are specified in the
instruction manual of your hob / oven / etc.
REQUIRED MINIMUM DISTANCE HOOD TO
ceramic-glass rings / hotplates
min. 65.00 cm
gas cookers
min. 75.00 cm
coal / oil / stove wood firing
min. 85.00 cm
1. The minimum distances do not represent the required total height, but a
minimum value generated by adding the height of the hob (floor ↔ hob) and the
required minimum distance of the hob to the extractor hood (hob ↔ extractor
hood)
(floor ↔ hob)
+
(hob ↔ extractor hood)
=
MINIMUM INSTALLATION HEIGHT
2. Adapt the total installation height to the height of the user. Please note that the
extraction capacity of the appliance can decrease if installed at a large distance to
the hob.
WARNING! Never install the appliance below the required
minimum distance. If you ignore the required minimum distance, the
