~ 51 ~
2. Installation
NOTICE! Any damage caused by an appliance that is improperly installed
and improperly connected to the mains is not covered by the warranty or
guarantee.
We recommend carrying out the installation of the extractor hood by qualified
personnel. Damages caused by improper installation of the appliance are not
subject to the guarantee or warranty!
2.1 General installation instructions
➢ The load-bearing capacity of the wall / ceiling of the installation room must be
checked before you install the appliance.
➢ The appliance must be installed at a suitable position only.
➢ Before you install the appliance, check that there are not any electrical or other
cables in the installation area; this prevents these cables from being drilled
unintentionally.
➢ Clean the environment thoroughly before installation. This prevents dust or
rubble from being sucked in during initial operation of the appliance.
➢ DURING INSTALLATION: ensure that the extractor hood is in horizontal position
in order to avoid accumulations of fat in one corner of the appliance.
2.2 Important installation instructions: extraction mode
WARNING! Do not lead the exhaust air into a chimney which is used
for extracting exhaust air of appliances operated by gas or other
combustibles.
➢ For extracting the exhaust air always observe the current legal regulations.
➢ The diameter of the exhaust hose must meet the diameter of the connecting ring.
➢ If your appliance is equipped with a carbon filter, remove the carbon filter before
you operate the appliance in the extraction mode. The carbon filter should be
used in the recirculating mode only.
➢ The exhaust duct should be as short and straight as possible. The diameter of the
exhaust hose should be at least 120 / 150 mm (look at chapter TECHNICAL DATA).
Otherwise, you have to expect increased noise and decreased performance of
your appliance.
➢ The proper maximum bending angle outwards is 120°.
➢ Use smooth tubes or flexible, non-inflammable exhaust hoses only.
➢ When the exhaust duct is connected horizontally, a minimum falling gradient of
1 cm/m or an inclination of 2° is required. Otherwise, condensate will get into
the motor of the hood.
