Phoenix Contact UM EN MACX series_en_02

Decimal ad-

dress

Hexadecimal

address

Numbers of

registers

Description Unit Data type

30001 0x0000 1 Hardware version

e.g.: 0x1000, means 1.000

/ Uint16

30002 0x0001 1 Software version

e.g.: 0x1001, means 1.001

/ Uint16

30003 0x0002 4 Serial number

(transmit from big Endian)

/ Hex

30007 0x0006 2 Order no.: first digit defaults to 0, which is null

(transmit from big Endian)

/ Hex

30101 0x0064 1 Default function mode: 0

0=WS: for MACX-MR-3V-690-R-PT;

0=W: for MACX-MR-V-600-R-PT, MACX-MR-C-10-

R-PT;

/ Uint16

30102 0x0065 2 Default upper threshold:

425: for MACX-MR-3V-690-R-PT, MACX-MR-V-600-

R-PT;

2.5: for MACX-MR-C-10-R-PT;

V/A Float32

30104 0x0067 2 Default lower threshold:

360: for MACX-MR-3V-690-R-PT;

375: for MACX-MR-V-600-R-PT;

1.5: for MACX-MR-C-10-R-PT;

V/A Float32

30106 0x0069 2 Default hysteresis:

5: for MACX-MR-3V-690-R-PT?MACX-MR-V-600-R-

PT;

0.5: for MACX-MR-C-10-R-PT;

V/A Float32

30108 0x006B 2 Default response delay time: 0.1 s Float32

30110 0x006D 2 Default start override time: 5 s Float32

30112 0x006F 1 Default relay operation principle: 0 (closed circuit) / Uint16

30113 0x0070 1 Default reset mode: 0 (auto reset) / Uint16

30114 0x0071 1 Default value of whether the function of phase se-

quence reversal monitoring is enabled: 1 (ON)

(Only for MACX-MR-3V-690-R-PT)

/ Uint16

30115 0x0072 1 Default value of whether the function of asymmetry

monitoring is enabled:1 (ON)

(Only for MACX-MR-3V-690-R-PT)

/ Uint16

30116 0x0073 1 Default value of asymmetry monitoring: 30

(Only for MACX-MR-3V-690-R-PT)

% Uint16

30117 0x0074 1 Default value of whether configuration via app is en-

abled: 1 (ON)

/ Uint16

30118 0x0075 1 Default device address: 1 / Uint16

30119 0x0076 1 Default baud rate: 2 (9600bps) / Uint16
