Inline product groups

6452_en_11 Phoenix Contact 27 / 188

5.2.3 Transmission speed in the local bus

It is possible to operate at a transmission speed of 500 kbps or 2 Mbps within an Inline

station.

Items designed for 2 Mbps are indicated by the extension "-2MBD" in the order designa-

tion. The versions without this extension are designed for 500 kbps.

In the product range, terminals with 500 kbps are basic versions. Some (not all) of

the terminals are also available as 2MBD versions. Information about available ter-

minals can be found on the Internet at phoenixcontact.com/products

.

NOTE:

Use the same transmission speed throughout an Inline station. The station cannot

operate otherwise. Make sure that your bus coupler supports this transmission

speed in the local bus.

For INTERBUS, a separate bus coupler version is available for each transmission speed.

Bus couplers for other bus systems may only support terminals with 500 kbps or even

both transmission speeds in the local bus.

For details of which transmission speed your bus coupler can use within the local

bus, please refer to the corresponding documentation.

Examples Examples of order designations:

Convention for this

document

The PAC version for 500 kbps is used in the following examples. However, all information

also applies for the versions for 2 Mbps and the versions without accessories.

IB IL 24 DO 4-PAC 500 kbps; complete with accessories (connector and labeling field)

IB IL 24 DO 4-2MBD-PAC 2 Mbps; complete with accessories (connector and labeling field)
