IL SYS INST UM E

26 / 188 Phoenix Contact

6452_en_11

5.2.1.2 ECO version (IB IL ...-ECO)

ECO version

Inline ECO terminals enhance the Inline portfolio by inexpensive and especially simple

terminals providing basic functionality. You can recognize these terminals by the “ECO”

specified in the order designation. You can install Inline ECO terminals in series behind

Inline bus couplers or Inline controllers, and combine them with standard terminals.

Please note that if an Inline ECO terminal is used, the permissible ambient temperature

for the station is limited to 0 °C to 55 °C.

Features of Inline ECO terminals

– No parameterization required (for digital and analog input and output terminals)

– Limited temperature range for operation: 0 °C ... 55 °C

– Scope of supply: electronics base and required connectors

– Analog and function terminals come without shield plug.

For notes on shielding, please refer to Section “Connecting cables using Inline

connectors” on page 128.

– Labeling fields are not included.

For ordering data for labeling fields, please refer to the Section “General acces-

sories” on page 162.

5.2.2 Scope of supply

Depending on the type, Inline terminals are available with varying accessories. Type “-

PAC” and “-ME” Inline terminals come with:

– The electronics base,

– all required Inline connectors, and

– all required labeling fields.

Inline connectors are designed for connecting the cables. They are required for correct

operation of the terminal.

Labeling fields are used for clear marking. They are optional accessories.

In the past, Inline terminals were available as stand-alone items without accessories. For

a stand-alone item without accessories, the Inline connectors have to be ordered sepa-

rately.

If your item comes without labeling field, you can separately order labeling fields as op-

tional accessories.

Table 5-2 Scope of supply for Inline terminals, depending on the type

Type (example) Connector Labeling field

IB IL 24 DO 4-PAC included in scope of supply included in scope of supply

IB IL 24 DO 4-ME included in scope of supply included in scope of supply

IB IL 24 DO 4/EF-ECO included in scope of supply accessories (optional)

IB IL 24 PWR IN accessories (required) accessories (optional)
