IL SYS INST UM E

160 / 188 Phoenix Contact

6452_en_11

Voltage dips and interrupts to the I/O supply

Intensity PS1 Interrupt time < 1 ms

Time interval between voltage dips < 1 s

Behavior Evaluation criterion 1

A dip in the supply voltage < 1 ms is not registered by the

bus.

Intensity PS2 Interrupt time < 10 ms

Time interval between voltage dips < 1 s

Behavior Evaluation criterion 3

Bus disconnection, all system outputs are reset.

Current and voltage distribution in data and potential jumpers

See Section “Current and voltage distribution” on page 91.

Cable connection method/cross-section

Cable connection method for the extra-low voltage and

low voltage levels

Spring-cage terminals

Cable connection method for the power level Screw terminals

Cable cross-section for the extra-low voltage and low volt-

age levels

typical (solid/stranded) 0.08 mm² ... 1.5 mm² , AWG 28 ... 16

for UL approvals (solid/stranded) 0.2 mm² ... 1.5 mm², AWG 24 ... 14

Cable cross-section for the extra-low voltage and low volt-

age levels

(Connection of the protective conductor PE)

1.5 mm²; AWG 16; cable is as short as possible

Cable cross-section for the power level

(Power connection, motor connection, brake connection)

(stranded and solid cables)

0.2 mm² ... 2.5 mm²; AWG 28 ... 14

Length of the sensor/actuator cables

For digital terminals < 30 m

For analog terminals See Section “Maximum cable lengths for analog devices”

on page 168

Electrically isolated areas

See terminal-specific data sheets.
