Inline: Technical data and ordering data

6452_en_11 Phoenix Contact 161 / 188

Air and creepage distances (according to EN 50178, VDE 0109, VDE 0110)

Isolating distance Clearance Creepage dis-

tance

Impulse voltage

withstand level

Technology for 24 V area

Incoming bus/bus logic 0.3 mm 0.3 mm 0.5 kV

Outgoing bus/bus logic 0.3 mm 0.3 mm 0.5 kV

Incoming bus/outgoing bus 0.3 mm 0.3 mm 0.5 kV

Bus logic/I/O 0.3 mm 0.3 mm 0.5 kV

Technology for area up to 250 V DC

Bus logic/I/O 3.1 mm 1.1 mm 4 kV

Technology for 230 V AC area single-phase (up to 253 V AC); safe isolation according to EN 50178

Bus logic/I/O 5.5 mm 5.5 mm 6 kV

I/O/PE 3.2 mm 3.2 mm 4 kV

Technology for 400 V AC area three-phase; safe isolation according to EN 50178

Bus logic/400 V AC I/O 5.5 mm 3.2 mm 6 kV

24 V DC I/O/400 V AC I/O 5.5 mm 3.2 mm 6 kV

Bus logic/24 V DC I/O 0.3 mm 0.3 mm 0.5 kV

Relay outputs

Main contact/N/O contact See terminal-specific data sheet

Relay contact/bus logic See terminal-specific data sheet

Test voltages

Isolating distance Test voltage

Technology for 24 V area (up to 60 V DC)

For information about the test voltages between the bus and other potential areas, please refer to the documentation

for the bus coupler.

7.5 V communications power, 24 V bus coupler sup-

ply/functional ground

500 V AC, 50 Hz, 1 min.

7.5 V communications power, 24 V bus coupler supply/24

V main supply, 24 V segment supply

500 V AC, 50 Hz, 1 min.

24 V main supply, 24 V segment supply/functional ground 500 V AC, 50 Hz, 1 min.

Technology for area up to 250 V DC

Bus logic/I/O 2500 V AC, 50 Hz, 1 min.

Technology for 230 V AC area single-phase (up to 253 V AC)

Bus logic/I/O 2500 V AC, 50 Hz, 1 min.

Routine test 1200 V AC, 50 Hz, 1 min.

Relay outputs

Main contact/N/O contact 1000 V AC, 50 Hz, 1 min.

Relay contact/bus logic 2500 V AC, 50 Hz, 1 min.
