Technical data and ordering data
8220_en_06 PHOENIX CONTACT 61
7 Technical data and ordering data
7.1 Technical data
General data
Dimensions (width x height x depth) 130 mm x 27 mm x 145 mm
Weight 550 g, approximately
Connection data for plug-in connector
Connection method Spring-clamp connection
Conductor cross section solid/stranded 0.2 mm
2
... 2.5 mm
2
Conductor cross section [AWG] 26 ... 12
Use copper wire that is approved up to 75 °C.
Power supply
Connection Via COMBICON plug
U
S1
, U
S2
24 V DC
Permissible range 18.5 V DC to 30 V DC
Ripple 3.6 V
PP
Power consumption (typical) 4.5 W
Current consumption (maximum) 250 mA
WARNING: Loss of electrical safety and the safety function when using unsuitable power supplies
The FL PN/PN SDIO-2TX/2TX is designed exclusively for protective extra-low voltage (PELV) operation
according to EN 60204-1. Only PELV according to the defined standard may be used for supply purposes.
The following applies to the network and the I/O devices used in it:
Only use power supply units that meet EN 61204 with safe isolation and PELV according to EN 50178/VDE
0160 (PELV). This prevents short circuits between primary and secondary sides.
Select the correct power supply units
Refer to the information on selecting the power supply unit in “Electrical safety” on page 11.
Only use power supply units with safe isolation with 24 V DC.
