Errors: Messages and removal

8220_en_06 PHOENIX CONTACT 57

5.4 PROFINET diagnostic messages/alarms

The safe PROFINET gateway supports the following diagnostic messages which can also

be sent as an alarm. Alarms for supply voltage U

are disabled by default, however

they can be enabled in the device parameterization. The diagnostic messages/alarms listed

in the sections below are possible:

5.4.1 PROFINET diagnostic messages/alarms

The following applies to all PROFINET diagnostic messages/alarms listed below:

UserStructureIdentifier: 8000

hex

Table 5-2 PROFINET diagnostic messages/alarms

ChannelErrorType Slot LED Error cause Description

0002

hex

SF1

Input voltage U

too low or

not present

–

SF2

Input voltage U

too low or

not present

–

0010

hex

2SF1/SF2

Process data length for slot 2

parameterized differently

The process data length set for slot 2 of

the safe PROFINET gateway is different

in both PROFINET systems.

0040

hex

SF1

Incorrect parameterization of

F_Dest_Add (1)

The F-Address of the safe PROFINET

gateway in PROFINET system 1 that was

parameterized via the software does not

correspond to the address set via DIP

switch F1.

SF2

Incorrect parameterization of

F_Dest_Add (2)

The F-Address of the safe PROFINET

gateway in PROFINET system 2 that was

parameterized via the software does not

correspond to the address set via DIP

switch F2.

0041

hex

3SF1/SF2

Incorrect parameterization of

F_Dest_Add (1)/

F_Dest_Add (2)

The F-Addresses of the safe PROFINET

gateway that were parameterized via the

software are the same in PROFINET

systems 1 and 2.

Incorrect DIP switch setting

(F_Dest_Add (1)/

F_Dest_Add (2))

The F-Addresses of the safe PROFINET

gateway that were set via DIP switches

are the same in PROFINET systems 1

and 2.

0042

hex

3SF1/SF2

Incorrect parameterization of

F_Source_Add (1)/

F_Source_Add (2)

The F-Addresses of the higher-level safe

PROFINET controllers that were

parameterized via the software are the

same.
