FL PN/PN SDIO-2TX/2TX

PHOENIX CONTACT 8220_en_06

SLOT3_PLUGGED_X,

PROFINET system 1

TRUE

Slot 3 of the safe PROFINET gateway (PROFINET IO device in

PROFINET system 2) is plugged/parameterized.

FALSE

Slot 3 of the safe PROFINET gateway (PROFINET IO device in

PROFINET system 2) is not plugged/parameterized.

SLOT3_PLUGGED_X,

PROFINET system 2

TRUE

Slot 3 of the safe PROFINET gateway (PROFINET IO device in

PROFINET system 1) is plugged/parameterized.

FALSE

Slot 3 of the safe PROFINET gateway (PROFINET IO device in

PROFINET system 1) is not plugged/parameterized.

SL3_S_COM_FAULT_X,

PROFINET system 1

TRUE PROFIsafe communication error in PROFINET system 2.

FALSE No PROFIsafe communication error in PROFINET system 2.

SL3_S_COM_FAULT_X,

PROFINET system 2

TRUE PROFIsafe communication error in PROFINET system 1.

FALSE No PROFIsafe communication error in PROFINET system 1.

NAME_ERROR_X,

PROFINET system 1 and

PROFINET system 2

TRUE

The PROFINET IO device names for the PROFINET gateway are

the same in both PROFINET systems.

FALSE

The PROFINET IO device names for the safe PROFINET gateway

have not been assigned (device naming not carried out) or they are

different in both PROFINET systems.

F_ADDR_ERROR_X,

PROFINET system 1 and

PROFINET system 2

TRUE

The F_Destination_Addresses of the safe PROFINET gateway that

were set via DIP switches are the same in both PROFINET systems.

FALSE

PROFINET system 1:

Slot 3 of the safe PROFINET gateway (PROFINET IO device in

PROFINET system 1) is not parameterized or the set

F_Destination_Addresses for the safe PROFINET gateway are

different in both PROFINET systems.

PROFINET system 2:

Slot 3 of the safe PROFINET gateway (PROFINET IO device in

PROFINET system 2) is not parameterized or the set

F_Destination_Addresses for the safe PROFINET gateway are

different in both PROFINET systems.

SLOT2_PD_LEN_ERROR_X,

PROFINET system 1 and

PROFINET system 2

TRUE

The process data length set for slot 2 of the safe PROFINET

gateway is different in both PROFINET systems.

FALSE

The process data length set for slot 2 of the safe PROFINET

gateway is the same in both PROFINET systems.

Table 5-1 Bits of the diagnostic/status word at slot 1

Bit Name State Meaning
