Errors: Messages and removal

8220_en_06 PHOENIX CONTACT 55

IN_SDATA_VALID_X (slot 3),

PROFINET system 1

TRUE

PROFIsafe communication between safe PROFINET controller 1

and the safe PROFINET gateway (PROFINET IO device in

PROFINET system 1) is synchronized and safe IN/OUT process

data is being transmitted.

FALSE

– PROFIsafe communication between safe PROFINET controller

1 and the safe PROFINET gateway (PROFINET IO device in

PROFINET system 1) is not synchronized and substitute values

(= 0) are being transmitted as safe process data.

– Slot 3 of the safe PROFINET gateway (PROFINET IO device in

PROFINET system 1) is not parameterized.

– An error has occurred in the safe PROFINET gateway.

IN_SDATA_VALID_X (slot 3),

PROFINET system 2

TRUE

PROFIsafe communication between safe PROFINET controller 2

and the safe PROFINET gateway (PROFINET IO device in

PROFINET system 2) is synchronized and safe IN/OUT process

data is being transmitted.

FALSE

– PROFIsafe communication between safe PROFINET controller

2 and the safe PROFINET gateway (PROFINET IO device in

PROFINET system 2) is not synchronized and substitute values

(= 0) are being transmitted as safe process data.

– Slot 3 of the safe PROFINET gateway (PROFINET IO device in

PROFINET system 2) is not parameterized.

– An error has occurred in the safe PROFINET gateway.

PNIO_PRM_X, PROFINET

system 1

TRUE

Communication connection established between PROFINET IO

controller and safe PROFINET gateway (PROFINET IO device in

PROFINET system 2) and the safe PROFINET gateway is parame-

terized.

FALSE

No communication connection between PROFINET IO controller

and safe PROFINET gateway (PROFINET IO device in PROFINET

system 2) and/or the safe PROFINET gateway is not parameterized.

PNIO_PRM_X, PROFINET

system 2

TRUE

Communication connection established between PROFINET IO

controller and safe PROFINET gateway (PROFINET IO device in

PROFINET system 1) and the safe PROFINET gateway is parame-

terized.

FALSE

No communication connection between PROFINET IO controller

and safe PROFINET gateway (PROFINET IO device in PROFINET

system 1) and/or the safe PROFINET gateway is not parameterized.

Table 5-1 Bits of the diagnostic/status word at slot 1

Bit Name State Meaning
