FL PN/PN SDIO-2TX/2TX

58

PHOENIX CONTACT 8220_en_06

5.4.2 PROFINET diagnostic messages/alarms under STEP 7

The following applies to all PROFINET diagnostic messages/alarms listed below:

UserStructureIdentifier: 8002

hex

0013

hex

3

SF1

PROFIsafe communication

error in PROFINET system 1

The PROFIsafe connection is faulty (not

synchronized).

SF2

PROFIsafe communication

error in PROFINET system 2

001B

hex

3SF1/SF2

Internal device error

– In the PROFINET part of

the device, e.g., internal

device watchdog (FS

LED is off or flashing)

– In the safety-related part

of the device (FS LED is

on)

Remedy:

Remove the cause of the error (e.g.,

Ethernet network overload due to

unintentional ring structures).

This operating state can only be exited

by switching the supply voltage of the

safe PROFINET gateway off and on

again.

In addition, this state can be exited by

means of a device reset if the error has

occurred in the non-safety-related part of

the device.

Table 5-2 PROFINET diagnostic messages/alarms

ChannelErrorType Slot LED Error cause Description

For more detailed information on STEP 7, please refer to the online help for the software.

Table 5-3 PROFINET diagnostic messages/alarms (STEP 7)

ChannelErrorType ExtChannelErrorType Slot LED Error message

8001

hex

8000

hex

0

– Wrong partner

8001

hex

– Wrong partner port

8004

hex

– Inconsistent MRP configuration/wiring

8005

hex

– Could not detect neighboring device
