FL PN/PN SDIO-2TX/2TX

52

PHOENIX CONTACT 8220_en_06

5.3 Bit assignment of diagnostics slot 1

The individual bits of the diagnostic/status word at slot 1 have the following meaning:

Please note that a diagnostic/status word is available for each of the two PROFINET

systems connected to the safe PROFINET gateway; it can be viewed in the engineering

software.

Table 5-1 Bits of the diagnostic/status word at slot 1

Bit Name State Meaning

0 US1_OK

TRUE Supply voltage U

S1

present and within the permissible range.

FALSE

– Supply voltage U

S1

not present.

– Supply voltage U

S1

present, but outside the permissible range

(< 18.5 V DC).

1 US2_OK

TRUE Supply voltage U

S2

present and within the permissible range.

FALSE

– Supply voltage U

S2

not present.

– Supply voltage U

S2

present, but outside the permissible range

(< 18.5 V DC).
