FL PN/PN SDIO-2TX/2TX

PHOENIX CONTACT 8220_en_06

– Ensure the cable shields for Ethernet are correctly secured in the plug-in connectors

and when routing a cable through a control cabinet.

– Only use shielded data cables. As much of the shield as possible must be connected

to ground on both sides.

– Immediately following entry in the control cabinet or housing, connect as much of the

cable shield as possible to a shield/protective conductor bar and secure the shield with

a cable clamp. Lead the shield to the module without interruption; connect it here but

not to ground.

– The connection between the shield/protective conductor bar and the control

cabinet/housing must have no impedance.

– Only use metal or metal-plated plug housing for shielded data cables.

3.2 Mounting the FL PN/PN SDIO-2TX/2TX

Set the DIP switches on the device prior to mounting. For additional information, please

refer to “DIP switches – PROFIsafe addresses” on page 33.

Only mount the device on DIN rails in accordance with DIN EN 60715.

Degree of protection of the device when mounted: IP20.

To ensure correct operation, the device mounted on a DIN rail must be installed in a

housing or a control cabinet with at least IP54 protection.

Shielding

The shielding ground of the connected twisted pair cables is electrically connected to the

RJ45 socket of the FL PN/PN SDIO-2TX/2TX. When connecting network segments, avoid

ground loops, potential transfers, and voltage equalization currents via the braided shield.

NOTE:

Please observe the following notes when using a shield connection clamp.

To avoid contact resistance only use clean, corrosion-free DIN rails. Before mounting the

devices, an end clamp should be mounted on the left-hand side next to the

FL PN/PN SDIO-2TX/2TX to stop the devices from slipping on the DIN rail. The end clamp

should only be mounted on the right-hand side once the FL PN/PN SDIO-2TX/2TX has

been mounted.

The following end clamps can be used:

– E/NS 35N (Order No. 0800886, fixed using a screw)

– CLIPFIX 35 (Order No. 3022218, snapped on without tools)

– E/UK (Order No. 1201442, fixed using screws)
