Diagnostics in the Axioline F system
8663_en_08 Phoenix Contact 9 / 38
2.1.2.3 LED states on I/O modules and backplanes
Meaning in Table 2-3:
1)
Firmware of the bus head does not support passive Smart Elements
2)
Firmware of the bus head supports passive Smart Elements
Table 2-3 D and E LEDs on the power connectors of the I/O modules and on Axioline F backplanes
Designa-
tion
Color Meaning State Description
D Red/
yellow/
green
Diagnostics for local bus communication
Run Green on The device is ready to operate.
The communication within the station is OK.
The controller is providing valid process data.
There is no malfunction.
Active Flashing
green
The device is ready to operate.
The communication within the station is OK.
The controller is not providing valid data.
No malfunction has occurred on the module.
– Backplane: The backplane slot is configured for a passive Smart
Element.
2)
Device applica-
tion not active
Flashing
green/
yellow
The device is ready to operate.
The communication within the station is OK.
The controller is providing valid process data.
There is a malfunction on the I/O side of the module.
The process output data cannot be output and/or the process input
data cannot be read in.
Backplane:
There is a malfunction on the I/O side of the Smart Element.
The process output data cannot be output and/or the process input
data cannot be read.
Ready Yellow on The device is ready to operate, but has still not detected a valid
cycle after power up.
