UM EN AXL F SYS DIAG
18 / 38 Phoenix Contact
8663_en_08
2.4 Diagnostic registers of the AXC ... controllers
You can use system variables to access the diagnostic registers of an AXC ... controller
and read the information.
Table 2-10 System variables of the diagnostic status register
System variable Type Meaning
AXIO_DIAG_STATUS_REG_HI BYTE Diagnostic status register (high byte)
AXIO_DIAG_STATUS_REG_LOW BYTE Diagnostic status register (low byte)
AXIO_DIAG_STATUS_REG_PF BOOL I/O error
AXIO_DIAG_STATUS_REG_PW BOOL I/O warning
AXIO_DIAG_STATUS_REG_BUS BOOL Bus error
AXIO_DIAG_STATUS_REG_RUN BOOL Data transmission is active
AXIO_DIAG_STATUS_REG_ACT BOOL Selected configuration is ready to operate
AXIO_DIAG_STATUS_REG_RDY BOOL Axioline F local bus is ready to operate
AXIO_DIAG_STATUS_REG_SYSFAIL BOOL When the controller is in the STOP state or there is no
program present on it, the Axioline F local bus switches to
the SYSFAIL state
.
Table 2-11 System variables of the diagnostic parameter register
System variable Type Meaning
AXIO_DIAG_PARAM_REG_HI BYTE Diagnostic parameter register 1 (high byte)
AXIO_DIAG_PARAM_REG_LOW BYTE Diagnostic parameter register 1 (low byte)
AXIO_DIAG_PARAM_2_REG_HI BYTE Diagnostic parameter register 2 (high byte)
AXIO_DIAG_PARAM_2_REG_LOW BYTE Diagnostic parameter register 2 (low byte)
