Diagnostics in the Axioline F system
8663_en_08 Phoenix Contact 19 / 38
2.5 Diagnostic registers of the AXL F BK ... bus couplers
The diagnostic registers of the local bus master can be read via the diagnostic mecha-
nisms of the higher-level system (see Table 2-12).
Further options for diagnostics:
For devices with web-based management:
• Open the “Diagnostics” menu item.
You can call the diagnostics for the bus coupler and local bus here.
When using the Startup+ software:
• Right-click on the bus coupler to open the context menu and select the “Diagnos-
tics” menu item.
You can call the diagnostics for the station and the individual devices here.
Table 2-12 Diagnostic mechanisms of higher-level systems
Bus coupler Higher-level
system
Diagnostic mechanism See Web-based
management
AXL F BK PB PROFIBUS Diagnostics in common format,
block 6, bytes 9 ... 12
UM EN AXL F BK PB No
AXL F BK EC EtherCAT
®
CoE object F100
hex
:
Axioline Bus Coupler Diag Info
DB EN AXL F BK EC No
AXL F BK PN ... PROFINET Diagnostic alarms DB EN AXL F BK PN ...
UM EN PROFINET SYS
Yes
AXL F BK ETH ... Ethernet Modbus registers:
Local bus diagnostics:
7997 diagnostic status register
7998 diagnostic status register 1
7999 diagnostic status register 2
I/O diagnostics:
1801 ... 1989 I/O diagnostics of the
local bus devices
DB EN AXL F BK ETH ... Yes
AXL F BK EIP ... EtherNet/IP™ Axioline F diagnostic object
(class code 67
hex
)
UM EN AXL F BK EIP -
OBJECTS
Yes
AXL F BK S3 Sercos IDN S-0-1500.0.134 DB EN AXL F BK S3 No
AXL F BK SAS IEC 61850 Yes
