43BDL4650D/50BDL4650D/55BDL4650D
64
Factory reset
Cancel Reset
ENERGY STAR
®
7.2.6. Configuration2 menu
O
On
Action
Action
Action
DP 1.1
1.4
OSD turn off
OSD H position
OSD V position
OSD transparency
Logo
Monitor ID
Heat status
Monitor information
DP version
HDMI EDID
45
50
50
Main
Auto
Action
English
Action
Window selection
RGB range
Rotation
Language
Configuration2 reset
Screen
Audio
PIP
Configuration 1
Configuration 2
Advanced Option
Screen
Audio
PIP
Configuration 1
Configuration 2
Advanced Option
OSD turn o
Set the period of time the OSD (on-screen display) menu stays
on the screen.
The options are: {0 ~ 120} seconds.
OSD H-position
Adjust the horizontal position of OSD menu.
OSD V-position
Adjust the vertical position of OSD menu.
OSD Transparency
Adjust OSD transparency.
• {O} - Transparency o.
• 20/40/60/80/100.
Logo
Choose to enable or disable the picture of Logo when turning
on your display.
The options are:
• {O}
• {On}
• {User}
NOTE: If it is set to {USER}, the rotation function is not
supported for user logo.
Monitor ID
Set ID number for controlling the display via the RS232C
connection. Each display must have a unique ID number when
multiple sets of display are connected. Monitor ID number
range is between 1 to 255.
The option are: {Monitor group} / {Tiling matrix} / {Auto ID}
Monitor ID
Monitor ID
Monitor group
Tiling matrix
Auto ID
1
1
1
End
• {Monitor group}
The options are: {1-255}. The default setting is 1.
• {Tiling matrix}
Tiling matrix number range is between 1 to 15. 1 is the
default setting. The {Auto ID} setup function enables setting
up {Monitor ID} of connected machine according to {Tiling
matrix} settings.
Example: Tiling matrix sets to 4
1 2
5 6
3
4
7 8
9 10 11 12
13 14 15 16
• {Auto ID}
The option are: {Start} / {End}. The default setting is {End}.
• Switch to Start to set up the IDs of machines backward
from current one.
• Once the setup is completed, the option exits from End
automatically.
• To use this function, serially connect all machines with
RS-232 cable and set their Control ports to RS-232 too.
Heat status
This function allows you to check the thermal status of display
at any time.
