43BDL4650D/50BDL4650D/55BDL4650D
65
Monitor information
Show information about your display, including model number,
serial number, operating hours and software version.
Monitor information
Model name
Serial NO.
Operator hours
SW Version
XXXXXX
74 H 33 M
V0.217
DP Version
The options are: {DP 1.1} / {DP 1.2}. The default setting is {DP
1.1}.
HDMI edid
The option are: {HDMI 1.4} / {HDMI 2.0}. The default setting is
{HDMI 1.4}.
NOTE: HDMI 2.0 option is to support HDMI 2.0 equipment.
Window selection
Select the window for adjusting the settings. The selected
window will be highlighted with green frame.
The options are: {Main}(Default), {Sub 1}, {Sub 2} , {Sub 3} .
RGB Range
The options are: {Auto} / {Full (PC)} / {Limited (Video)} The
default setting is {Auto}.
Rotation
Set the rotation of Main/Sub/OSD
• Auto Rotate : O/On,Default : O
Auto Rotate: {O}, {On} when value is On,automatically
detect whether the PD rotation, O is set by OSD.
• OSD Rotate : Landscape/Portrait,Default : Landscape
OSD Rotate: {O}, {On} when value is on, OSD rotate 270 °,
O is restored.
• Image rotation: O/On,Default : O
Image rotation: {O}, {On} when value is on, all Window
screen with the support input source* rotate 270 °, O is
restored
Support input source: Media Player / BROWSER / PDF Player /
Custom / Interact
NOTE: When the Main / Sub1(2/3) in PIP/PBP mode is one of
the support input source, the rotation is given priority to the
last setting.
Language
Select the language used in the OSD menu.
The options are: English/Français/Deutsch/Español/Italiano/
简
体中文 / 繁體中文 /Português/ 日本語 /
Polski / Türkçe / Русский
/ العربية / Danish / Svenska / Suomi / Norsk / Nederlands /
Čeština / Eesti / Latviešu / Lietuvių.
Conguration2 reset
Reset all settings in Conguration2 menu to the factory preset
values.
7.2.7. Advanced option menu
Auto
Action
Action
Action
Off
Action
Action
Action
Action
Action
Input resolution
IR control
Keypad control
Tiling
Off timer
Date and time
Schedule
Auto Restart
HDMI with One Wire
Auto Signal Detection
Screen
Audio
PIP
Configuration 1
Configuration 2
Advanced Option
Input resolution
Set the resolution of VGA input. This is only required when the
display is unable to detect the VGA input resolution correctly.
NOTE: This item applies to VGA input only.
The options are:
• {1024x768 / 1280x768 / 1360x768 / 1366x768}
• {1400x1050 / 1680x1050}
• {1600x1200 / 1920x1200}
• {Auto}: Determines the resolution automatically.
The selected settings will become eective after turning o the
power and turning it on again.
IR control
Select the operation mode of remote control when multiple
displays are connected via an RS232C connection.
• {Normal} - All displays can be operated normally by the
remote control unit.
• {Primary} - Designate this display as the primary display for
remote control operation. Only this display can be operated
by the remote control.
• {Secondary} - Designate this display as the secondary display.
This display can not be operated by the remote control, and
will only receive the control signal from the primary display
via the RS232C connection.
• {Lock All} / {Lock all but Volume} / {Lock all but Power}
/ {Lock all except PWR & VOL}- Lock the remote control
function of this display. To unlock, press and hold the [ ]
INFO button on the remote control for 5 (ve) seconds.
NOTE:
1. [ ]
Hot key to display the Primary / Secondary OSD
2. Press [ ] or [ ] button to display the Primary / Secondary
OSD in the case of DisplayPort / VGA / DVI-I / HDMI1 /
HDMI2 and no OSD display.
3. In the Primary OSD, press [ ] or [ ] button to adjust the
value of {Control Monitor ID}, and press [ ] or [ ] button
to adjust the value of {Control Group ID}.
Keypad Control
Select to enable or disable the display keyboard (control
buttons) function.
• {Unlock} - Enable the keyboard function.
