18
OPERATION INSTRUCTIONS
(Continued)
9. CONTINUOUS FAN MODE
Control the fan speed. Press to select the fan speed in
four steps: LOW, MED, HIGH and AUTO. The fan speed
indicator light illuminates underdierent fan settings.
NOTE: When in Cooling or Dry mode, press
the Fan button for 3 seconds to turn on or o
the constant fan function.
Benets of the continuous Fan Function:
The continuous fan function oers several
advantages for maintaining a comfortable indoor
environment. When enabled, the fan continues
to run even after the set temperature is reached,
ensuring continuous air circulation throughout
the room. This helps prevent stagnant air and
promotes more even cooling or dehumidication,
reducing hot or humid spots.
For those who prefer continuous airow, such as
during the night or in larger rooms, this feature
enhances overall comfort. If continuous air
movement is not needed, the function can be
turned o for a more tailored cooling experience.
10. OTHER FEATURES
FOLLOW ME feature
The Follow Me feature allows the remote control
to act as a portable thermostat, providing precise
temperature control based on the remote's
location rather than the air conditioner's. This
helps create an even temperature throughout the
room, eliminating hot and cold spots.
1. Stand near the air conditioner and point the
remote control directly towards the unit.
2. Press the Follow Me button on the remote control.
The air conditioner will then use the temperature
reading from the remote control's location to
adjust the room temperature accordingly.
3. The remote control will continuously send the
Follow Me signal to the air conditioner until you
press the button again to deactivate the feature.
If the unit does not receive a signal from the
remote control for any 7-minute interval, it will
automatically exit the Follow Me mode.
This feature is not available when the unit is in
FAN or DRY mode.
By using the Follow Me feature, you can ensure
the most comfortable temperature where you
are in the room, not just near the air conditioner.
7. AUTO mode
• When you set the air conditioner to
AUTO mode, it will automatically choose
between cooling and fan-only operation,
based on the temperature you have
selected and the current room temperature.
• Use the Up and Down arrows to set your
desired room temperature. The fan speed is
not adjustable in this mode.
• The air exhaust hose must be installed in the
window when the unit is in AUTO mode.
• When in AUTO mode, you can not select the
fan speed.
8. DISPLAY
• The control panel can display the temperature
in either Fahrenheit or Celsius. To switch
between these two units, press and hold
both the Up and Down buttons simultaneously
for 3 seconds.
When you select Auto, Dry, or Cool mode, the
display panel will show the set temperature.
When you select Fan mode, the display panel
will show the current room temperature.
• Error Codes and Their Meanings:
EH00: EEPROM error.
EH60: Room temperature sensor error.
EH61: Evaporator temperature sensor error.
EC52: Condenser temperature sensor error
(on some models).
EH0b: Display panel communication error.
EC: Refrigerant leakage detection
malfunction(on some models).
• Shows protection code:
P1: Bottom tray is full. Connect the drain hose
and drain the collected water. If the P1
code does not clear, contact service.
NOTE: When one of the above malfunctions
occurs, turn o the unit, and check for
any obstructions. Restart the unit, if the
malfunction is still present, turn o the unit
and unplug the power cord. Contact the
manufacturer, it's service agents or a
similar qualied person for service.
