23
GB/IE/NI/CY
Screw the connection system onto the G 1”-
pipe thread clockwise until it is firmly attached.
Attach the companion piece for the connection
system to the pressure hose and stick both parts
into one another.
Attaching the Pressure Pipe Con-
nection System G1½"
Screw the adopter
9
off the connecting piece
12
by rotating in anti-clockwise direction .
Place the non-return valve
10
in the connection
opening of the connecting piece
12
.
Screw the connection system onto the G1½"
pipe thread clockwise until it is firmly attached.
Attach the companion piece to the connection
system to the pressure hose and stick both parts
into one another.
Operating and servicing the
appliance
Adjusting the Float Switch
NOTE! RISK OF DAMAGE!
Improper handling of the appliance can result in
damage to the appliance.
Make sure that the float switch cannot be-
come entangled in foreign objects (e.g. roots,
grilles, etc.).
The appliance is automatically switched on and
off with the aid of the float switch
5
.
The appliance will switch off on its own if the float
switch
5
is tilted downwards more than 45°.
The appliance will turn on automatically if the float
switch
5
is titled upwards more than 45°.
The float switch
5
must be adjusted so that it can
be raised and lowered in the location where it is
deployed. Make sure that the float switch
5
does
not touch the floor or soil before the appliance is
switched off.
Press the clamps for the float switch height
adjustment mechanism
8
together and push
them into the mount
7
for the float switch .
Once you have done this, release the clamps.
Adjust the switch-on/switch-off point by
- adjusting the position of the float switch height
adjustment mechanism
8
.
- adjusting the length of the float switch
cable
6
. Push/pull the float switch cable
6
through the eyelet on the float switch height
adjustment mechanism
8
.
A position that is adjusted lower and a cable
that is adjusted shorter are appropriate for a
low water level.
A position that is adjusted higher and a cable
that is adjusted longer are appropriate for a
high water level.
Immersing the Appliance in
Water
WARNING!
RISK OF ELECTRIC
SHOCK!
Faulty electrical installation or excessive system
voltage can result in electric shock.
Make sure that the power plug is situated in a
flood-proof area.
Make sure that no persons are present in the
area that is to be drained.
NOTE! RISK OF DAMAGE!
Improper handling of the appliance can result in
damage to the appliance.
Do not install the appliance by suspending it
with the aid of the pressure hose or the power
cable.
Observe the maximum immersion depth.
Observe the potential discharge head.
Make sure the maximum water temperature is
not exceeded.
Check to make sure that the pressure pipe is
firmly attached to the appliance.
Make sure that the area to be drained has
dimensions of at least 40 x 40 x 50 cm, so that
the float switch can move freely.
Immerse the appliance in the water at an
angle, so that no air bubbles can form in the
suction area
4
.
Place the appliance upright once it has been
completely immersed.
Let the appliance slowly sink to the bottom
while holding onto the retaining cable
13
.
Carry out a test run at low water level.
Make sure the appliance is standing firmly on
the floor of the working area.
Plug the power plug for the connecting cable
2
into a properly installed power outlet.
The appliance will begin pumping automati-
cally.
Assembly / Operating and servicing the appliance
