GB
13
Structure with central tube shaft (9):
Depending on body size, the round
handle (13) can be mounted
a) between the two soft grips (27)
or
b) between the swivel star tube shaft
of the device housing (11) and the
soft grip (27).
The dismantling takes place in reverse order.
Initial Operation
Do not use the equipment
without the hand guard.
Wear suitable clothing and work
gloves when working with the
equipment.
Ensure that the equipment is func-
tional before each use. The On/Off
switch and the safety switch must
not be held closed. They must switch
off the motor when on is released.
Should a switch be damaged, stop
working with the equipment. Ensure
that the mains voltage value match-
es the label on the equipment.
Note noise protection and local
specications. The use of the equip-
ment on certain days (e.g. Sundays and
national holidays), at certain times of day
(lunch times, night time quiet periods) or in
special areas (e.g. health resorts, clinics
etc.) is restricted or forbidden.
D
Swivelling Out the
Blade Beam
1. Hold the safety blade beam (1) on the
handle to adjust the blade beam (5).
2. Unlock the safety lever (3) and keep it
pressed.
3. By simultaneously exerting pressure on
the lock lever (4), you will loosen the
xation of the cutter bar (1).
4. The safety blade beam (1) can now be
swivelled out. Use the stop stages and
allow the stop lever (4) to click back in.
You can choose 9 stop stages.
5. Then, release the safety lever (3) again
and ensure that it latches back into its
initial position.
Attach the shoulder strap
Warning! Never wear the car-
rying strap diagonally across
your shoulders and chest: only wear
it on one shoulder to ensure you can
detach the device quickly from your
body in the event of danger.
Place the shoulder strap on one shoulder.
Attach the shoulder strap spring clip (19)
to the carrying eyelet (20) on the tubular
shank of the device. Set the strap length
such that the spring clip on the shoulder
strap is roughly at the height of your hip.
Sliding the carrying eye
You can slide the carrying eye (20) to bet-
ter spread the weight of the device.
You may need to slide the soft grip (27)
by turning and sliding to achieve this.
1. Loosen both screws (28) with an Allen
key (4 mm).
2. Gently retighten the screws (28).
3. Place on the shoulder strap and attach
the device to the shoulder strap. (See
“Attaching the shoulder strap”)
4. Slide the carrying eye (20) until the
weight of the device is spread evenly.
5. Put the device down and tighten the
screws (28).
