GB
14
A
Removing the knife
guard
Press the knife guard (21) on the location
marked „Parkside“ and remove it.
A
Switching On and Off
Ensure that you are standing in a
rm position with both hands grip-
ping the hedge trimmer away from the
body. Ensure that the trimmer is in contact
with no other objects before switching on.
1. Make a loop in the beginning of the
mains cable and suspend this in the
cable strain relief (18).
See Fig. for correct use of the
strain relief.
2. Connect the device to the mains voltage.
3. To switch on, hold the safety switch (15)
depressed and simultaneously press the
on/off switch (16). The hedge trimmer
will be run at maximum speed. You can
release the safety switch (15) again.
4. The equipment will switch off again
when you release on/off switch (16).
A
Working with the
Electric Hedge Trimmer
During cutting work, ensure that no
contact is made with objects, e.g.
such as wire fencing or main plant stems.
This may result in damage to the cutter bar.
• To avoid eye injuries, always wear the
supplied safety goggles while working
with the hedge trimmer (22).
• Always hold the equipment rmly in
both hands, with one hand on the rear
handle and the other on the front han-
dle (13). Thumbs and ngers must be
rmly around the handles.
• Check the shoulder strap (19) on a
pleasant position, which makes it easier
for you to hold the hedge trimmer.
• Switch off the equipment immedi-
ately in the event that the blades are
blocked by solid objects, pull out the
power plug then remove the object.
• Always work away from the mains
power outlet. Set the cutting direction
before starting work. Ensure that the
power cable is kept well away from
the working area. Never lay the cable
over the hedge, where it could easily
be caught up in the trimmer blades.
• Avoid overstraining the equipment dur-
ing work.
Pull out the power plug imme-
diately if the cable is dam-
aged, badly twisted or has been
completely cut through. Risk of elec-
tric shock!
A
Putting down the device
• Place the device on the ground with
the motor housing rst.
• The safety cutter bar (1) must be
placed on the ground without being
subjected to any pressure.
• Do not apply any static pressure what-
soever to the cutter bar (1).
E
Swivelling the Arm
Caution!
The gear box (2) becomes hot
during operation. There is a
risk of burns. Do not touch the
gearbox housing (2) or the
connecting point to the front
tubular shaft (6).
