8
|
GB / IE
CAUTION!
► If you use the angle stop3 and the
height stopr at the same time, make
sure that the saw discp does not
come into contact with the height
stopr!
Adjusting the height stop
♦ Undo the height stop lockt. Turn the
height adjustment knob e until you
reach the desired setting.
♦ The values in the scale windowsw
serve as a reference. The set height is
shown by the ▼ markings.
♦ After you have set the height, retighten
the height stop lockt.
Removing the height stop
♦ Undo the height stop lockt.
♦ Turn the height adjustment knobe
clockwise until you reach the highest
setting and you can remove the height
stopr.
Changing the saw disc (see Fig.E)
WARNING! RISK OF INJURY!
Switch o the appliance and
disconnect it from the mains
before carrying out any work
on it.
♦ Set up the appliance so that the rear
side of the blade guard2 is facing
towards you.
♦ Undo the screws on the rear of the
blade guard2 using a Phillips screw-
driver (not supplied; see Fig.F).
♦ Pull the blade guard 2 forwards o
the appliance.
♦ Press the spindle locku and keep it
pressed. Check whether the saw discp
still turns. If yes, turn the saw discp
until the spindle locku clicks into
place.
♦ Insert the face spanner4 into the cor-
responding holes on the angeo. Undo
the angeo using the face spanner4
by turning it in the direction indicated by
the arrows on the saw discp and the
appliance.
♦ Remove the angeo and the saw
discp from the spindle.
♦ Insert the new saw disc and check that
the direction of rotation is correct using
the arrows on the disc and appliance
(direction of rotation arrow a).
♦ To reassemble, proceed in reverse order.
■ Before use, check to ensure that the
blade guard2 closes properly. When
the saw discp retracts from a cut, it
must retract completely into the blade
guard 2.
■ Always carry out a test run without load
before starting work and after replacing
an accessory tool. Switch o the product
immediately if the accessory tool runs
unevenly, if there is a signicant vibra-
tion or if you hear unusual noises.
Use
WARNING!
■ Never activate the spindle locku
while the saw discp is still turning.
■ Before use, check to ensure that the
blade guard2 closes properly. When
the saw discp retracts from a cut, it
must retract completely into the blade
guard 2.
■ Keep your hands out of the sawing
area and away from the saw disc p
while the appliance is switched on!
