Fitting the dust bag
♦ Put the appropriate end of the extraction
nozzle 6 onto the chip ejector d.
♦ Use two ngers to press the spring
clip7 on the opening of the dust bag
together.
♦ Push the opening of the dust bag over
the other end of the extraction nozzle6.
♦ Let go of the spring clip7.
♦ To dismantle, proceed in reverse order.
Emptying the dust bag
To ensure optimum dust extraction, empty
the dust bag 8 regularly.
♦ Open the zip on the dust bag 9.
♦ Shake out the dust bag 8 over a
suitable waste container.
Setting the biscuit groove size
(seeFig. B)
The appliance can cut biscuit grooves in
six sizes. To do this, use the depth adjust-
mentq.
Setting Biscuit type Cutting depth
0 No. 0 approx. 8 mm
10 No. 10 approx. 10 mm
20 No. 20 approx. 12.3 mm
S Simplex approx. 13 mm
D Duplex approx. 14.7 mm
Max - approx. 20 mm
♦ Turn the depth adjustmentq until the
desired biscuit groove size is set on the
▼ marking on the upper side.
Setting the biscuit groove depth
(seeFig. B)
You can adjust the depth of the biscuit
groove if the depth of the biscuit groove
does not correspond with the size of the
biscuit you are using.
♦ Turn the depth adjustment screw 0
with a Phillips screwdriver (not supplied):
clockwise: reduce cutting depth
anticlockwise: increase
♦ Carry out a test on some scrap material
to check that the setting is correct.
Angle setting (see Fig. D)
The angle stop3 is adjustable to cut slots
with dierent angles.
♦ Loosen the angle stop screwz by
turning it anticlockwise.
♦ Set the desired angle using the angle
scalei and the ▼ marking above it.
♦ Re-tighten the angle stop screwz by
turning it clockwise.
Height stop
The height stopr is tted in front of the
angle stop3. The height stop r can be
adjusted to match the thickness of the
workpiece.
Fitting the height stop
♦ Undo the height stop lockt.
♦ Align the lower part of the height stopr
with the upper side of the angle stop3.
Press the height stopr downwards.
The gear wheel on the back of the height
adjustment knobe must engage in the
grooves of the angle stop3.
♦ Turn the height adjustment knobe
in both directions to test whether the
height stopr can move in both direc-
tions.
IB_458729_PFDF900C3_LB8.indb 7IB_458729_PFDF900C3_LB8.indb 7 11.07.2024 11:34:5111.07.2024 11:34:51
