15GB/IE/NI
Removing the foam lance
1. Press down the foam lance [].
2. Rotate the foam lance [] in anti-clockwise
direction.
3. Remove the foam lance [] from the pressure
washer [1].
Attaching/removing the
water hose
(Fig. H)
Attaching the water hose
1. Align the hose coupler [] of the water
hose [9] to the water inlet connector [5].
2. Insert the hose coupler [] into the water
inter connector [5] until it is click-locked.
Removing the water hose
1. Hold the upper part of the hose coupler [].
2. Pull the hose coupler [] away from the
water inlet connector [5].
Filling cleaning agent
(Fig. I)
1. Hold the foam lance [].
2. Rotate the cleaning agent bottle [] in anti-
clockwise direction.
3. Remove the foam lance [] from the
cleaning agent bottle [].
4. Fill the cleaning agent bottle [] with liquid
cleaning agent.
5. Insert the foam lance [] into the cleaning
agent bottle [].
6. Rotate in clockwise direction to lock the
cleaning agent bottle [] to the foam
lance [].
m
CAUTION!
u This product has been designed to be
used with a biodegradable cleaning
agent. Other cleaning agents or chemical
substances may impair the safety of the
product and damage it. Such damage to
the product is not covered by warranty.
Adjusting the nozzles
(Fig. J)
The spray nozzle [8] has 6 different spray
patterns that can be used.
Rotate the spray nozzles [8] to select the
spray patten.
White icons on the top of the spray
lance [7] indicate which spray nozzle [8] is
selected.
Icon Spray pattern/angle
0°
15°
25°
40°
Gentle spray for watering, irrigation
or washing.
Water jet that sprays upward.
m
CAUTION!
The product is not suitable for
connecting to a drinking water
supply system directly.
Noise and vibration emission value
Sound pressure level L
pA
: 71.5 dB
Uncertainty K
pA
: 3 dB
Sound power level
measured
L
WA
: 82.5 dB
Uncertainty K
WA
: 3 dB
Guaranteed sound
power level
86 dB
Noise level specification
L
WA
: 86 dB
