12
NI
Switching on and off (Fig. F)
Switching on:
•
2
Press the On/Off switch.
Switching off:
• Release the On/ Off switch
2
.
Speed adjustment (Fig. G)
• The speed can be adjusted using the
speed regulator
6
according to the
requirements. This can be done when the
machine is being operated, with 1 being
the lowest and 6 being the highest speed.
Function selection (Fig. E)
NOTE!
The selector switch should only be used
when the motor has stopped completely.
Never work with chisel in inserted
(hammer) drilling position or with the
drill inserted in the chisel position.
• Unlock the function selector switch
3
using
the unlocking latch
4
and hold it pressed.
• Turn the function selector switch so that
the arrow marking points at the desired
operation symbol.
- Drilling. For drilling wood, steel and
similar materials.
- Hammer drilling. For hammer drilling of
concrete, granite and similar materials.
- Rotation stop. Adjusting the chisel
position. For continuous adjustment of the
axis. Then rotate the function selector switch
back to the Chiselling position.
- Chiselling. For light chiselling or
chipping.
• Release the unlock latch.
• Check if the function selector switch is
locked in place by trying to rotate it without
pressing the unlocking latch.
WARNING!
Do not apply excessive force on
the hammer drill. Excessive pressure
may damage the drill, chisel or the
hammer drill and increases the risk of
accident.
Always secure your workpiece
in a vice or in any other clamping
device. Secure particularly large
workpieces against sliding or
support them properly.
For this reason is it important to
always grip the drill firmly with
two hands and maintain a stable
posture. The greater the diameter of
the drill bit, the greater is the force on
your arm.
Drilling and chiselling
Drilling
• Choose a drill bit appropriate for the
application and insert it into the tool as
described in chapter 'Inserting the tools'.
• Insert the drill bit properly at the desired
location.
• Press the On / Off switch
2
to start
drilling.
Hold the hammer drill firmly with
your dominant hand using the
vibration-proof handle
5
and hold
the additional handle
9
with your
other hand.
Drilling with keyed chuck
13
(Fig. H)
NOTE!
The keyed chuck
13
should be used
only when the impact drilling function is
switched off.
