Technical Specifications
WARNING: Do not use this product outside of the specified performance and environmental limits. Failure to comply with
these specifications could result in product failure, personal injury, or death.
WARNING: The VeriSafe 2.0 AVT is designed for use in 50 or 60Hz AC electrical systems and DC electrical systems. The AVT
should not be installed on sections of a circuit where the AVT is exposed to high frequency energy such as variable frequency
drives (VFD) or other circuit elements generating high frequency energy (waveforms exhibiting high Electro-Magnetic Inter-
ference (EMI)). For more information on where to position the VeriSafe 2.0 AVT in VFD applications, see the Technical Note
available on Panduit.com.
Special Conditions
of Use
Hazardous Locations
Refer to Page 2 of this manual for all Special Conditions of Use for Hazardous Locations.
Environmental Ratings
Operating Temperature -25°C to 60°C (-13°F to 140°F)
Storage Temperature -45°C to 85°C (-49°F to 185°F)
Humidity 5 to 90% non-condensing; Rated 80% at 40°C (104°F), decreasing linearly to 50% at 60°C (140°F)
Pollution Degree 3
Altitude Up to 5000 meters (16400 feet)
Applications
Electrical System For use in 3-phase AC systems, single-phase AC systems and DC systems
Voltage Detection Range Up to 1000 VAC (50 or 60 Hz), 1000 VDC
Absence of Voltage Threshold 3 V (See the Installation Considerations section for additional information)
Overvoltage Category III (1000 V), IV (600 V)
Degree of Protection Indicator Module: for flat surface mounting in a TYPE (UL, NEMA and CSA) 1, 12, 13, 4, 4X, IP66,
IP67 or IP69 enclosure. Verify that the seal, o-rings and gaskets are clean to ensure proper sealing.
Isolation Module: Open Type, IP20.
Power Requirements
Battery Industrial 3.6 V Lithium. Refer to Maintenance section for list of approved batteries.
Auxiliary (DC) Power 35 mA max @ 12 VDC; 17 mA max @ 24 VDC
Power over EtherNet (PoE) PoE (10/100), 15 mA, IEEE 802.at (-af) Type 1 Class III PoE topology
Quiescent Current
Battery Powered Per Phase: 0.85 mA rms @ 480 Vrms; 1.2 mA rms @ 1000 Vrms
Auxiliary (DC or PoE) Powered Per Phase: 0.33mA rms @ 480 Vrms; 0.65mA rms @ 1000 Vrms
Voltage Presence Indicators (Red LEDs) - Voltage Illumination Level
Voltage
Illumination Level
AC System Voltage DC System Voltage
Three-Phase Single-Phase 3-Wire Center Ground Positive or Negative Ground Isolated Ground
Battery Powered 50 VAC 60 VAC 90 VDC 55 VDC 90 VDC
Auxiliary Powered
(DC or PoE)
50 VAC 50 VAC 50 VDC 50 VDC 50 VDC
continued on next page
