98
English
■ [Image rotation]
Sets the picture rotation in the portrait setting.
[Off]:
Pictures are not rotated.
[180 degrees]:
Pictures are rotated 180 degrees.
Setting [Position] when [Image rotation] is set to
[180 degrees]
When [Image rotation] is set to [180 degrees], the
adjustment direction becomes opposite of that in [Off]
state. (see page 47)
Note these points for adjustment.
■ [POWER button control setting]
Sets the operation when the power button ( ) of the
main unit is pressed.
[Off]:
Turns off the power.
[Standby]:
Enters the standby mode.
■ [Power LED light-up setting]
Sets the display operation of the power indicator of the
main unit.
[Off]:
Does not illuminate.
[On]:
Illuminates according to the power status.
■ [PC input mode]
Set this mode according to the input signal format of the
PC IN terminal.
[PC]:
RGB signal
[PC[YP
BPR]]:
YP
BPR/YCBCR signal
Note
●
The synchronized signal supports the following inputs
only.
[PC]: HD/VD signal input only
[PC[YP
BPR]]: Only the synchronized signal
superimposed on Y signal input
■ [Use memory select]
Selects a memory to use.
[USB]:
Uses a USB memory.
[Internal memory]:
Uses the internal memory.
■ [USB (DEVICE) connect setting]
Sets the connection destination of the USB DEVICE
terminal.
[Auto]:
Switches the connection destination by the input
setting.
USB-C: Connects to the USB-C HOST terminal.
SLOT: Connects to the SLOT.
Other inputs: Connects to the internal system of
the main unit.
[USB-C]:
Connects to the USB-C HOST terminal.
[SLOT]:
Connects to the SLOT.
Other inputs: Connects to USB.
[Internal]:
Connects to the internal system of the main unit.
The same operation as that for the USB terminal
is performed.
Note
●
When [USB (DEVICE) connection switching] function
is executed, this setting is disabled. It is enabled by
setting again.
■ [USB-C/SLOT select]
Controls the power supply to the USB-C HOST terminal
and the SLOT terminal.
[USB-C]:
A maximum power supply of 60 W to the USB-C
HOST terminal is possible. In this case, SLOT
cannot be used.
[USB-C+SLOT]:
Both the USB-C HOST terminal and the SLOT
terminal can be used. Note that a maximum power
supply to USB is restricted to 7.5 W.
Note
●
For the main software is lower than Version of 2.6000,
after changing settings, turn off and on the <Main
power switch>, or disconnect and connect the power
plug from/to the outlet.
■ [LAN terminal setting]
Selects a terminal for LAN control.
[LAN terminal]:
Controls from the LAN terminal of the main unit.
[DIGITAL LINK SLOT]:
Controls from the LAN control terminal of the
DIGITAL LINK Terminal Board.
Note
●
When the DIGITAL LINK Terminal Board is not
attached, the menu is not displayed, and forced
control is performed by the LAN terminal of the main
unit.
●
The LAN control terminal of the DIGITAL LINK
Terminal Board does not support daisy chain
connection for LAN control.
