English
12
13
English
Notes:
a) When the hose is loose, steam may clog up in the hose
and noise may be heard.
b) Fill the water tank when the water level is too low.
c) Do not remove the water tank and hose from the power
base during use.
d) To close steam, turn off the power button.
e) Water may drip from nozzle on to the clothes, this is not a
malfunction.
f ) Turn off the power button, unplug the power plug when you
take out the water tank from the power base.
g) The maximum loading capacity of the hanger is 3 kg while
that of the hook is 2 kg.
h) Do not pull the clothing with force during use to avoid
product from falling over.
i ) Do not touch the steam, doing so may cause scalds.
j ) During the ironing process, water droplets may form on the
hanger part. It is normal for water droplets to dampen the
clothes.
k) Do not use the appliance with leather fabric.Test on an
inconspicuous area when using with expensive products,
special materials, and fabrics with less heat-resistance.
l ) When the steamer head is hung in the steamer holder, do
not hang items other than the steamer head in the steamer
holder, as this may cause the steamer holder to deform,
which may result in burns or injuries due to the fall of the
steamer head.
m) During use, if there is no water in the water tank, the power
indicator may go on and off, which is normal.
n) During use, please wear insulated gloves to smoothen
wrinkles with hands.
4. Steaming the clothes.
It is recommended to put the steam head into the steamer
holder when you sort out or change the clothes to be ironed.
5. Set the power button to “ OFF ” when you have
finished using, unplug the power plug.
3. It can be used after a maximum of 2 minutes of heating.
Please hold the steamer head by the shaded area.
USING THE GARMENT STEAMER
1. Hang clothes to be ironed on
hangers or hang it with a
hanger on the hanger hook.
Insert the power plug into
the household outlet.
2. Set the power button,
the power indicator
light should be on.
Level Steam level
Low steam
Middle steam
High steam
Start steaming
Approx. 75
seconds
Approx. 45
seconds
Approx. 30
seconds
Vertical steam ironing
Shaded area represents the hand-held area.
Tips:
If necessary, the hanger can be extended for use by pulling
the ends of the hanger to the maximum length on both sides
as shown in the picture.
Before extending the hanger, remove the steamer head and
adjust the height of the telescopic pole for easy operation.
HOW TO FILL WATER
The plug must be removed from the electrical outlet
before the water tank is filled with water.
1. Remove the water tank from power base.
2. Open the cap on the bottom of the water tank.
Put the water tank under a faucet and fill it with proper
amount of water.
Tighten the cap correctly.
3. Secure firmly the water tank
back to the power base.
Notes:
a) The water tank capacity is approx. 3.0 L, which is below
the water inlet. Fill it with proper amount of water
according to your need.
b) Please fill the water tank with tap water. In case you
live in an area with hard water, scales may build-up quickly
so using distilled water or purified water is recommended.
c) When filling water, water may accumulate in the groove
around the water inlet. This is not a malfunction. Please
clean any water in the groove before installing the water
tank back.
d) Do not move the product after filling water.
1
2
3
3
2
1
