When you need to do horizontal steam ironing, you can use
the horizontal steam ironing function by placing the ironing
board horizontally.
Horizontal steam ironing
1. Disconnect the power supply,
then remove the steam head
hook from the holder.
2. ①Remove the ironing board by
loosening the snap of the ironing board.
②Remove the hangers by first pressing the spring lock
underneath the hangers inward with a hard object.
Be careful to hold the product steadily when removing it so
that it does not tip over.
①
②
3. Turn the ironing board over and rotate the ironing board
ironing steamer holder approximately 180° in the direction
shown.
Approx.
180°
5. Align the hole on the telescopic pole with the telescopic
pole hole on the back of the ironing board, and press down
the ironing board to ensure that the telescopic pole is fully
inserted into the telescopic pole hole on the back of the
ironing board, and the spring lock snaps into the hole on
the telescopic pole.
4. Release the lock button at the bottom of the telescopic
pole to lower the height of the telescopic pole, and then
fasten the lock button.
6. Place the steamer head
into the steamer holder
on the ironing board.
7. At this time, the product
can be used for horizontal ironing.
Notes:
a.For horizontal ironing, the maximum load capacity of the
ironing board is 3 kg.
b.If the operating is incorrect, please reassemble again.
c.When doing horizontal ironing, the height of the ironing
board can be adjusted by adjusting the height of the
telescopic pole.
d.For horizontal ironing, set the power button to “ ”.
Refer to “Fabrics and ironing
recommendations”.
ACRYLIC, ACETATE,
NYLON, SILK,
POLYESTER, RAYON,
CHIFFON
Steam
Level
Fabric and ironing recommendations
WOOL, COTTON,
LINEN
To iron normal wrinkles from
thin clothing.
To iron normal wrinkles from
thick clothing.
Note:
Do not use the appliance on leather.
Test on an inconspicuous area when using with expensive
products, special materials, fabrics with less heat-resistance.
(Velvet, wool, cashmere, acrylic, silk, etc.)
Recommendations
To iron stubborn wrinkles
from thin clothing.
To iron stubborn wrinkles
from thick clothing.
Fabric
English
14
15
English
