EN - 16

ENGLISH

2.4.3 - Assembly of the air ducts and external grids

• Afterdrillingtheholes(withthecoredrill),inserttheplasticsheet(H)suppliedwiththeairconditioner

(g.11)insidethem.

 Cuta130mmaponthelongsidefromthesheet(H)(g.11).

The sheets must be 65 mm shorter than the length of the wall.

• Rollthesheet(H)andinsertitintothehole,payingattentiontothesplicingline,which must always

face upwards. (g.11).

 Useanordinarycutterfortheforegoingoperation(g.11-12).

To position the external grids, proceed as follows:

a. Applytheseal(G)tothewallange(D),ensuringitlinesupwiththeouteredgeoftheangeasindicated

inthegure13.

b. Fixthetwoangesusing2pegshavingadiameterof6mmandcheckthatthetwoxingholesare

horizontal(g.14-15-16).

c. Fitthesmalleyeletofthespring,withthelongstem,onthecappin(onbothcomponents)(g.17).

d. Insert the two caps (with spring), on the front part of the external grid, on its two housings, pulling until

itclicks(g.18)andcouplethetwochainstothelargeeyeletofthespring.

e. Using one hand, grip the two chains connected to the grid;

f. Bendtheexternalgridsback,grippingthemwithyourfreehandwheretheybend,andinsertyourngers

insidethesinglens(g.19).).

g. Insert your arm into the pipe until the grid protrudes completely outwards.

h. Reopenthegrid,beingcarefultokeepyourngersinsidethens.

i. Turnthegriduntilthensarefullyhorizontalandtilteddownwards.

l. Pullthechain,tensioningthespring,andcouplethechainringtothepinoftheinnerangethrough

whichthepipespass(g.20).

m. Use hand shears to cut off any excess chain links.

Use exclusively the supplied grids (F), or grids with like characteristics.

2.4.4 - Preparing the holes on the machine

The unit is designed exclusively for coupling with pipes for the exit and entry of air with a diameter of 162 mm.

2.4.5 - Positioning of the device on the anchor brackets

Workingonthetwopreviouslydrilledholes(seeg.6),xthesupportbrackets(L)tothewallusingthe

suppliedwallplugsscrews(E)(g.21).

After checking:

 thatthexingbracketsarewellanchoredtothewall,

that the installation site has been prepared for electrical connection and condensation discharge (if

necessary),

it is possible to hook the air conditioner.

Work as follows:

a. Applyadhesivetape(A)tohavereferencestothehookingpointsoftheunit(g.22).

The tape can be removed once the unit has been hooked to the wall.

b. Raisetheairconditionerholdingitbythesidesofthelowerbaseandhookittothebrackets(L)(g.23).

Slightly tilt the lower part of the appliance towards yourself to ease the operation.
