UNICO AIR INVERTER R32

EN - 15

ENGLISH

Carefully check the characteristics and consistency of the wall in order to possibly choose wall

plugs specic for particular situations.

The manufacturer will not be held liable for any underestimates made in the

structural consistency of the anchor prepared by the installer.

Therefore, pay utmost attention to the foregoing operation that could cause

serious injury/damage to people/property if carried out incorrectly.

• When installing models equipped with heating pump, if no condensate discharge was built into the wall

(see paragraph 2.4.2), in order to drain the condensate it will be necessary to drill a hole through the

wall in the position shown on the template.

2.4.2 - Preparing the condensate discharge

• Asregardsmachineswithheatpump,acondensationdrainpipe(g.1-ref.N)(supplied)tobeinserted

inthespecicconnection(A)(g.7).

 Removethecap(B)(g.7)beforeinsertingthecondensationdrainpipe.

 Whenthemaxlevelisreached,asolenoidvalveensuresthecondensatewillowoutfromtheinternal

tray.

• Forcold-onlymachines,connectthecondensatedischargepipeifyouintendrunningtheunitatlow

outdoor temperatures (lower than 23°C).

• Sincecondensatedrainsbygravity,theremustbeaminimumslopeofatleast3%ateverypointofthe

dischargeline.Usearigidorexibletubehavinganinsidediameterofatleast16mm.

• Ifthelineemptiesintoaseweragesystem,installasiphonbeforethepointinwhichthepipereaches

themaindischarge,atleast300mmbelowtheinletfromtheunit(g.8).

• Ifthedrainpipedrainsintoavessel(tankorothercontainer),thiscontainershouldnotbesealedand

thedrainpipeshouldnotremainimmersedinthewater(seeg.9).

• Thehole(J)throughwhichthecondensatepipepassesshouldalwaysslopetowardstheoutside(see

g.10).

The exact position in which to place the pipe inlet, as compared to the machine, is shown on the drilling

template.

Make sure, in this case, that the water expelled outward does not damage or

disturb persons or property.

During the winter this type of drainage may cause sheets of ice to form.

When the condensate drainage is tted, pay much attention not to compress

the rubber hose.

In the event of operation during the winter with temperatures equal to or lower than 0° C, make

sure that the condensate drain pipe is protected from freezing in order to ensure draining.

In the event of prolonged operation during the winter with temperatures below 5°C, install the

optional basin heater kit.
